Detail dry network

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Fire networks, Isometric power supply, Vent valve detail, scale, terrace, Reduction bb, Galv steel., Outlet mouth with storz for connection hose fire department, Valve mm., Llp steel galv., Mm., Detail griffin mural, scale, Dry mouth, Entrance mouth with union storz, Machon concrete, dog. Galv steel., Mm., Diam., sucker

Raw text data extracted from CAD file:

REDES CONTRA INCENDIO ISOMETRICA RED DE ALIMENTACION DETALLE VALVULA DE VENTEO ESCALA 1:10 TERRAZA \A1;0.76 REDUCCION BB 100 - 50 ACERO GALV. 100 BOCA DE SALIDA CON STORZ PARA CONEXION MANGUERA CUERPO DE BOMBEROS VALVULA D = 50 mm. LLp 50. ACERO GALV. D = 50 mm. DETALLE 3.- GRIFO MURAL ESCALA 1:5 ESCALA 1:10 DETALLE 1.- BOCAS DE ENTRADA RED SECA BOCA DE ENTRADA CON UNION STORZ MACHON HORMIGON CAÑ. ACERO GALV. D = 100 mm. DIAM. 75MM. VENTOSA B 50x20
