Detail Of Public Health DWG Detail for AutoCAD

Detail of public health

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

handrail, sink, handrail, Turning diameter, For chairs, wheel, toilet, handrail, pending, handrail, sink, toilet, handrail, entry, strainer, Sanitary detail, scale, Sanimodul brand stainless steel finisher, Recessed wall mirror, Gray marble cover, Wc pacifica one piece brand toto model color white, White toto, Floor interceramic model morelia color black, Washbasin ovalyn low cover large brand toto model color white, Screen sanimodul brand model stainless steel finish, Built-in wall mirror, Metal frame painted black, Stainless steel bobrik dispenser. mate, Ibero hand dryer, Automatic faucet pressmatic fv line, Washbasin ovalyn low cover large brand toto model color white, Wc pacifica one piece brand toto model color white, White toto, Sanimodul brand stainless steel finisher, Screen sanimodul brand model stainless steel finish, Fine

Raw text data extracted from CAD file:

A AR-01 Barra de apoyo Lavabo Barra de apoyo Diametro de giro para sillas de ruedas 2.45m. Inodoro Barra de apoyo Pendiente 2% Barra de apoyo Lavabo Inodoro Barra de apoyo Entrada Coladera DETALLE DE SANITARIO ESCALA 1:20 1 1 2 2 A A Divisorio de migitorio marca Sanimodul acabado en acero inoxidable Espejo de 9mm empotrado a pared Cubierta de marmol gris WC pacifica one piece marca TOTO modelo MS904114 color blanco Migitorio marca TOTO modelo UT104E-01 color blanco Piso marca Interceramic modelo Morelia 40x40cms color negro Lavabo ovalyn de bajo cubierta grande marca TOTO modelo LT597 color blanco Mampara marca Sanimodul modelo Imperio, acabado acero inoxidable Espejo empotrado a pared Bastidor metálico pintado de negro Dosificador de jab\U+00F3n Bobrik Inox. Mate 1100cc. Secador de manos Ibero \U+00F3ptico Grifo automático linea pressmatic de FV Lavabo ovalyn de bajo cubierta grande marca TOTO modelo LT597 color blanco WC pacifica one piece marca TOTO modelo MS904114 color blanco Migitorio marca TOTO modelo UT104E-01 color blanco Divisorio de migitorio marca Sanimodul acabado en acero inoxidable CORTE- A CORTE- 1 CORTE- 2 Mampara marca Sanimodul modelo Imperio, acabado acero inoxidable Enjarre apalillado fino Enjarre apalillado fino Enjarre apalillado fino Enjarre apalillado fino H= 1.10 H= 1.10 H= 1.10 H= 1.10

Language	Spanish
Drawing Type	Detail
Category	Bathroom, Plumbing & Pipe Fittings
Additional Screenshots
File Type	dwg
Materials	Steel
Measurement Units
Footprint Area
Building Features
Tags	autocad, bad, bathroom, casa de banho, chuveiro, DETAIL, DWG, health, lavabo, lavatório, PUBLIC, salle de bains, toilet, waschbecken, washbasin, WC
