Distribution Board DWG Block for AutoCAD

Typical installation of electric

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

variable, variable, trench, top, n.p.t, part., unity, cant, measurements in meters., brand, square, thick-walled galvanized steel conduit pipe, threaded in their required diameter., Jupiter, diameter required., counter nut iron monitor galvanized die cutter, angle of carbon steel of esp., bolt bolt standard expansion bolt, with hexagonal nut for fixing in, cat. do not., electrical commercial, ah okay, hilti, Galvanized steel screw of long., with flat wheel nut head., bar capacity assembly, with main switch derived according to needs, thread board, piece, meter, piece, meter, piece, piece, typical installation

Raw text data extracted from CAD file:

VARIABLE 1.50 VARIABLE 3 6 4 2 5 TRINCHERA TRINCHERA TAPA N.P.T PART. UNIDAD CANT. ACOTACIONES EN METROS. D E S C R I P C I O N MARCA SQUARE D TUBO CONDUIT DE ACERO GALVANIZADO POR INMERSION, PARED GRUESA ROSCADO EN SUS EXTREMOS, DE DIAMETRO REQUERIDO. JUPITER DIAMETRO REQUERIDO. CONTRATUERCA Y MONITOR DE FIERRO TROQUELADO Y GALVANIZADO DE ANGULO DE ACERO AL CARBON DE 3/16" DE ESP. X 1 1/2" X 1 1/2" PERNO EXPANSIVO TIPO "KWIK BOLT II" ESTANDAR DE 3/8" d, Y 3" DE LONGITUD, CON TUERCA HEXAGONAL Y ROLDANA, PARA FIJACION EN CONCRETO, CAT. NO. 00045363 COMERCIAL ELECTRICA AHMSA HILTI TORNILLO DE ACERO GALVANIZADO DE 1/4" DE DIAMETRO Y 1" DE LONG. CON CABEZA HEXAGONAL, TUERCA Y ROLDANA PLANA. 60 Hz, MONTAJE SOBREPONER, DE CAPACIDAD DE BARRAS REQUERIDA, CON INTERRUPTOR PRINCIPAL Y DERIVADOS SEGUN NECESIDADES TABLERO DE DISTRIBUCION, 220/120 VOLTS, 3 FASES, 4 HILOS 1 1 PIEZA METRO - 2 3 - PIEZA 4 - METRO 5 8 PIEZA 6 8 PIEZA TIPICO DE INSTALACIÓN 1

Language	Spanish
Drawing Type	Block
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials	Steel
Measurement Units
Footprint Area
Building Features	Car Parking Lot
