Electric Detail Rush A DWG Detail for AutoCAD

Electric Detail Rush A DWG Detail for AutoCAD

TWO ELECTRIC – LINE DIAGRAMTWO ELECTRIC DETAILS ONE IS ELECTRIC- LINE DIAGRAM AND OTHER IS ASSEMBLY ELECTRICAL CONNETCTION . DETAILS TO BE FROM THE CONNECTION TO MAIN BOARD

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

minimum, unscaled, Driver, Botaguas, Electric single line diagram, Thhn in conduit tube if, Two electrodes for grounding, Minimal coopelesca connection, Main board, minimum, Thhn phases thhn neutral thhn earth in conduit tube, N.p.t., Thermomagnetic main switch a., Thhn phases thhn neutral in emt tube, Meter meter, Thhn phases thhn neutral in emt tube, Conduit tube indicated in main board, Electrical connection assembly, unscaled, sidewalk, Concrete column build, Kilowatt hour meter, Of tail for the connection the public network, Mm boom rope, Emt tube of mm, main switch, Conductor ground in conduit of mm inside the column, Grounding connector register, Ground electrode mm

Raw text data extracted from CAD file:

\A1;.50 MINIMO SIN ESCALA 32mm.d CONDULETA BOTAGUAS DIAGRAMA UNIFILAR ELECTRICO 1#6 (TIERRA) THHN EN TUBO CONDUIT DE 13mm.d. (EMT SI ES EXPUESTO) DOS ELECTRODOS PARA PUESTA A TIERRA 3m x 16mm.d ACOMETIDA DE COOPELESCA Mínimo 30cm.DE COLA M TABLERO PRINCIPAL .50 MINIMO 2#4 THHN FASES 1#4 THHN NEUTRO 1#6 THHN TIERRA EN TUBO CONDUIT 32mm.d N.P.T. INTERRUPTOR PRINCIPAL TERMOMAGNETICO 90 A. 2#4 THHN FASES 1#4 THHN NEUTRO EN TUBO EMT 32mm.d MEDIDOR CLASE 100A 2#4 THHN FASES 1#4 THHN NEUTRO EN TUBO EMT 32mm.d \A1;159.80 \A1;20.11 \A1;68.00 \A1;0.50 \A1;19.91 TUBO CONDUIT PVC, d INDICADO EN TABLERO PRINCIPAL MONTAJE DE ACOMETIDA ELECTRICA SIN ESCALA 5 5 5 0.50 ACERA 5 COLUMNA DE CONCRETO A CONSTRUIR MEDIDOR DE KILOVATIOHORA 0.30 m DE COLA PARA LA CONEXION A LA RED PUBLICA CONDULETA BOTAGUA DE 32 mm TUBO EMT DE 32 mm INTERRUPTOR PRINCIPAL CONDUCTOR DE PUESTA A TIERRA EN CONDUIT DE 13 mm DENTRO DE LA COLUMNA REGISTRO DEL CONECTOR PARA PUESTA A TIERRA ELECTRODO A TIERRA DE 16x3000 mm

Language	Spanish
Drawing Type	Detail
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials	Concrete, Other
Measurement Units
Footprint Area
Building Features
Tags	ASSEMBLY, autocad, DETAIL, details, diagram, DWG, einrichtungen, electric, facilities, gas, gesundheit, l'approvisionnement en eau, la sant, le gaz, line, machine room, maquinas, maschinenrauminstallations, provision, rush, unifilar, wasser bestimmung, water
