Electrical Installation Housing DWG Block for AutoCAD

Electrical Installation Housing DWG Block for AutoCAD

electrical installations of a department – Plant with scheme Install, and legends box

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

study, dinning room, living room, dinning room, kitchen, Lav., kitchen, S.h., bedroom, S.h., Up stream, Arrives commutation, Arrives stream, Arrives commutation, legend, symbol, description, height, Center of light, Spot light, Bipolar outlet, Simple switch, Shock switch, commutation, pass box, doorbell, General board, Red on the wall, Red roof wall, Ring circuit

Raw text data extracted from CAD file:

ESTUDIO CL COMEDOR SALA SALA COMEDOR COCINA LAV. LAV. COCINA S.H S S S DORMITORIO S S S S.H Sa,b S Se,f e Sc,d S SUBE CORRIENTE LLEGA CONMUTACION J J LLEGA CORRIENTE LLEGA CORRIENTE LLEGA CONMUTACION a b c d s/c s/c LEYENDA SIMBOLO DESCRIPCION ALTURA CENTRO DE LUZ SPOT LIGHT TOMACORRIENTE BIPOLAR 0.4m S INTERRUPTOR SIMPLE 1.4m Sa,b INTERRUPTOR DE 2 GOLPES 1.4m s/c CONMUTACION 1.4m J CAJA DE PASO 0.4m-2.2m TIMBRE 2.2m TABLERO GENERAL 1.6m RED EN PISO O PARED RED EN TECHO O PARED CIRCUITO DE TIMBRE

Language	Spanish
Drawing Type	Block
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials
Measurement Units
Footprint Area
Building Features
Tags	autocad, block, box, department, DWG, einrichtungen, electrical, electricity, facilities, gas, gesundheit, Housing, install, installation, installations, l'approvisionnement en eau, la sant, le gaz, legends, machine room, maquinas, maschinenrauminstallations, plant, provision, SCHEME, wasser bestimmung, water
