Electrical Panel Nameplate drawing for 25kW Heater System

Industrial Heater Control Panel Specification

This technical drawing depicts the nameplate layout for an industrial heating system panel (“PAINEL AQUECEDOR”) designed for the UTE Novo Tempo Barcarena facility. This drawing serves as the identification and technical specification plate for a 25kW heater control panel with designation +P1 and equipment ID 16GBP20GH001.

Key Technical Specifications:
– Model/Product Code: 092304601P01
– Manufacture Date: 05/2024
– Nominal Power: 25kW
– Nominal Voltage: 460VCA/3F+PE/60Hz (460V AC, 3-phase with protective earth, 60Hz)
– Control Voltage: 110VCA / 24VDC (dual voltage control system)
– Nominal Current: 35A
– Short Circuit Current (Icu): 10kA
– Project Number: 09.23.046

Physical Characteristics:
– Dimensions (HxWxD): 800×600×300mm – a compact design for industrial installation
– Estimated Gross Weight: 90kg

The panel appears to be manufactured by SAT (Sistemas de Automação e Tecnologia), as indicated by their logo and contact information. The drawing includes the “DRAFT” watermark, suggesting this is a preliminary design document pending final approval. The extensive layer structure (376 layers) in the CAD file indicates this is part of a comprehensive electrical engineering documentation package.
