Electrical Substation DWG Detail for AutoCAD
Details about an electrical substation
Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):
Work no., Detail of pole lamp, cut, Concrete pole of m., Abrasive, Insulation reel ic, frame, Power transformer, Electrical substation, Substation side view, To the wall of attack, Front view substation, Air system, For transformers, Equipment materials, Ref, do not., Symbology, Volts, High voltage low voltage network, Abbreviated description, Concrete pole, insulator, Tie you up, Crosshead pt, frame, Suburban light v. S., Driver at home, Spool insulator for, Monopolar thermomagnetic switch, Half ring clamp to receive rush, Ground rod coperweld mm, Ib cabinet for lighting control, Public lighting measurement equipment, Muffled dry pipe, Single-phase distribution transformer, Autovalvular arresters ada, Bs clamp, Three-phase kV distribution transformer., Zinc oxide arresters, Electrical substation, Aci circuit breakers, Copper wire no. Awg. For earth system., Copperweld earth rod, Muff for tuba conduit, Cabinet for accommodating measuring equipment., General thermomagnetic switch a., Conduit tube of mca. omega., To support the transformer., Concrete oct, Vinanel cal., Work no., Electrical substation, High medium voltage, Single feed line, To the wall of attack, Front view substation
Raw text data extracted from CAD file:
| Language | Spanish |
| Drawing Type | Detail |
| Category | Water Sewage & Electricity Infrastructure |
| Additional Screenshots |
 |
| File Type | dwg |
| Materials | Concrete |
| Measurement Units | |
| Footprint Area | |
| Building Features | Pool, Car Parking Lot |
| Tags | alta tensão, autocad, beleuchtung, DETAIL, details, détails électriques, detalhes elétrica, DWG, electric substation, electrical, electrical details, elektrische details, haute tension, high tension, hochspannung, iluminação, kläranlage, l'éclairage, la tour, lighting, substation, torre, tower, treatment plant, turm |
