Symbols of accessories , circuits of planes electricity installation

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

general legend, special, ceiling, indicated, octog, indicated, of the, kind, indicated, boxes, heights, ceiling, oct., ceiling, description, kwh, symbol, three-phase kitchen, unipolar switch type triple balancin, electric lock activated by remote control., exit for intercom intercom., force output, pass box, bipolar tripolar switch of indicated amperage, external telephone distribution box, internal telephone distribution box, shock switch, bipolar socket with earth connection, Meter holder type, bipolar socket test with socket, exit on roof, exit for internal telephone., output for external telephone, exit for spot light, exit on wall, special, floor., grounding, water pump board, Power outlet distribution board strength., line with tw mm.d pvc, automatic switch type not fuse thermomagnetic., circuit embedded in floor tw pvc, circuit recessed in ceiling wall tw mm.d pvc, line with tw mm.d pvc, circuit embedded in floor tw pvc, pipe for recessed in ceiling wall mm.d, pipe for external telephone mm.d recessed in wall, pipe for internal phone mm.d recessed in wall

Raw text data extracted from CAD file:

P P LEYENDA GENERAL 0.40 100x100x55 100x55x50 ESPECIAL 1.00 1.40 100x55x50 1.20 TECHO 100x100x50 150x120x100 0.30 1.40 INDICADA 0.30 (B.I.) 0.30 (B.I.) 100x55x50 100x55x50 OCTOG. 100x55 100x55x50 INDICADA 1.20 0.30 DEL 0.30/1.10 0.30 TIPO "L" 0.60 (B.I.) 0.30/1.10 INDICADA 100x55x50 100x55x50 .30 .30 CAJAS (mm.) S.N.P.T.(EJE) ALTURAS 100mm.d TECHO OCT. 100x40 OCT. 100x40 2.10 TECHO DESCRIPCION Pt/a S 2S 2S3 S3 Pt/a Kwh 3S SIMBOLO SALIDA TRIFASICA PARA COCINA INTERRUPTOR UNIPOLAR SIMPLE, DOBLE, TRIPLE (15A,220V) TIPO BALANCIN CERRADURA ELECTRICA ACCIONADA POR MANDO A DISTANCIA. SALIDA PARA INTERCOMUNICADOR PORTERO. SALIDA DE FUERZA CAJA DE PASO CAJA DE PASO 15A - 220V. INTERRUPTOR BIPOLAR O TRIPOLAR DE FUSIBLES, AMPERAJE INDICADO CAJA DE DISTRIBUCION DE TELEFONOS EXTERNOS CAJA DE DISTRIBUCION DE TELEFONOS INTERNOS INTERRUPTOR DE CONMUTACION (3VIAS) 15A-220V. DE 1y2 GOLPES . TOMACORRIENTE BIPOLAR DOBLE, CON TOMA A TIERRA 15A - 220V. CAJA PORTAMEDIDOR TIPO "L" TOMACORRIENTE BIPOLAR SIMPLE, A PRUEBA DE HUMEDAD, CON TOMA A TIERRA, SALIDA EN TECHO (CENTRO) SALIDA PARA TELEFONO INTERNO. SALIDA PARA TELEFONO EXTERNO SALIDA PARA SPOT LIGHT (HALOGENO DICROICO) SALIDA EN PARED (BRAQUETE) ESPECIAL ESPECIAL 1.80 (B.I.) O PISO. O PISO. TOMA DE TIERRA TABLERO DE BOMBA DE AGUA (TBA) TABLERO DE DISTRIBUCION DE ALUMBRADO, TOMACORRIENTES Y FUERZA. LINEA CON 3-1 x 2.5 mm.2 TW - 15 mm.d PVC - L INTERRUPTOR AUTOMATICO TIPO NO FUSE TERMOMAGNETICO. 10KA, 240V, 60c/s. CIRCUITO EMPOTRADO EN PISO 2-1x2.5mm.2 TW - 15mm.d PVC - L CIRCUITO EMPOTRADO EN TECHO O PARED 2-1x2.5mm.2 TW - 15 mm.d PVC - L LINEA CON 4-1 x 2.5 mm.2 TW - 20 mm.d PVC - L LINEA CON 5-1 x 2.5 mm.2 TW - 20 mm.d PVC - L LINEA CON 6-1 x 2.5 mm.2 TW - 25 mm.d PVC - L CIRCUITO EMPOTRADO EN PISO 2x4mm.2 TW +1x4mm2/T - 15mm.d PVC - L TUBERIA PARA TV-CABLE EMPOTRADA EN TECHO O PARED 25 mm.d PVC-L S/A. TUBERIA PARA TELEFONO EXTERNO 20 mm.d PVC-L S/A. EMPOTRADA EN PARED TUBERIA PARA TELEFONO INTERNO 20 mm.d PVC-L S/A. EMPOTRADA EN PARED 1.80 (B.I.)
