Elevators 1 DWG Model for AutoCAD

Elevators 1 DWG Model for AutoCAD

Standard model elevators with board for calculate

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

mm., traction elevators in, capacity, door, cabin, pit, machine room, hook, hatch, kgs, pers, last stop, travel, intermediate stop, min., min. mm., cut, machine room, pit plant, traction elevator scheme generalities, first stop

Raw text data extracted from CAD file:

\A1;2500mm. \A1;2000mm. \A1;L \A1;RECORRIDO \A1;MIN. 2400MM. \A1;H \A1;G \A1;F \A1;1.00 \A1;N \A1;M \A1;MIN. 300 MM. \A1;E \A1;D \A1;C \A1;B \A1;A ASCENSORES DE TRACCIÓN (MEDIDAS EN MILÍMETROS) CAPACIDAD V=0.8/1.2 V=1.2/2.0 PUERTA CABINA FOSO SALA MAQUINAS GANCHO ESCOTILLA REACCIONES(KG.) KGS PERS. H L H L A B C D E F G K M N R1 R2 R3 450 6 1500 4000 1800 4500 800 1220 940 1800 1600 2200 4000 800 900 1200 3200 3000 5500 600 8 1500 4000 1800 4500 800 1220 1263 1800 2000 2300 4000 800 1050 1500 3400 3200 6500 750 10 1500 4000 1800 4500 900 1520 1190 2050 1950 2500 4300 800 1050 1500 3600 3400 7500 900 12 1500 4000 1800 4500 1000 1620 1290 2150 2000 2600 4500 1000 1050 1500 3800 3600 8500 975 13 1500 4000 1800 4500 1000 1670 1340 2150 2100 2700 4800 1300 1100 1700 4400 3800 9000 1050 14 1500 4000 1800 4500 1000 1770 1340 2250 2100 2700 4800 1500 1100 1700 4600 4000 9500 1200 16 1500 4000 1800 4500 1000 1920 1390 2450 2150 2700 5000 1800 1200 1900 4800 4200 10000 \A1;K 2500mm. 2000mm. L ULTIMA PARADA RECORRIDO PARADA INTERMEDIA MIN. 2400MM. H \A1;R1 R2 G F 5 N M MIN. 300 MM. \A1;R3 E D C B A CORTE ESC:1/50 SALA DE MAQUINAS ESC:1/50 PLANTA FOSO ESC:1/50 ESQUEMA DE ASCENSOR DE TRACCIÓN GENERALIDADES PRIMERA PARADA

Language	Spanish
Drawing Type	Model
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials
Measurement Units
Footprint Area
Building Features	Elevator
Tags	ascenseur, aufzug, autocad, board, cálculate, DWG, einrichtungen, elevador, elevator, ELEVATORS, facilities, gas, gesundheit, l'approvisionnement en eau, la sant, le gaz, machine room, maquinas, maschinenrauminstallations, model, provision, standard, wasser bestimmung, water
