Facade Section DWG Section for AutoCAD

Facade Section DWG Section for AutoCAD

Section at roof level

Drawing labels, details, and other text information extracted from the CAD file (Translated from Portuguese):

Partial cut of the cover, scale, leaf, Caption: rigid steaming metal pendant separation rolled thermal separator in cms stone. Metallic locking cms drop. Thermal drain ventilated air

Raw text data extracted from CAD file:

18 19 Corte parcial da cobertura Escala 1/10 Folha 11/16 17 16 Legenda: 01-Suporte rigido 02-Barreira de vapor 03-Formação de pendente (Ais-Texsa) 04-Camada de separação 05-Tela (Morter-Plas) 06-Tela (Morter-Plas) 07-Tela (Morter-Plas Aluminio) 08-Ralo metálico 09-Seixos rolados 10-Tela separadora (Terram) 11-Isolamento térmico (Roofmate) 12-Vedante 13-Reboco 14-Tela 15-Encabeçamento em pedra 16-Tijoleira 17-Tijolo de 15 cms. 18-Elemento metálico de travamento 19-Tubo de queda 20-Reboco 21-Tijolo de 11 cms. 22-Isolamento térmico 23-Caixa de ar drenada e ventilada 1 2 20 21 22 23 3 4 5 6 9 10 11 7 8 12 13 15 14

Language	Portuguese
Drawing Type	Section
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials
Measurement Units
Footprint Area
Building Features
Tags	autocad, barn, cover, dach, DWG, facade, hangar, lagerschuppen, Level, roof, section, shed, structure, terrasse, toit
