Finished Box DWG Block for AutoCAD

Finished Box DWG Block for AutoCAD

Finished industrial boxes

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

finish box, house level machine, second floor, injection ship, control, outdoor ramps, replacements warehouse, vehicle circulation, stairs, car rental, stairs, first floor, finish box, iron, painting, synthetic enamel paint in metalwork, tempered glass aluminum fittings, acrylic latex paint, matt oil painting on walls, mirror running, crystals, satin stainless steel handrail, with balusters, tempered glass aluminum fittings, plywood doors with mdf, finished with acrylic paint, mad, carpentry, painted latex, finished with enamel paint, drywall, Metal door, bars, tarrajeo impermeabilizado, transparent eternit iron, turn it up, polished concrete, vinyl, waterproof cement, ceramic mm, color, plinth, plastering for painted plaster, plating, walls columns, polished polished mm., waterproof cement, roll vinyl with soft base mm., ceramic of intense traffic, floors, finished, of environment, departures, asphalt layer for vehicular track, Precor cover similar type, iron ladder type cat, public income, pedestrian path, House of machines, distribution board, sub station station, sh. males, sh. women, office of supervision, House of machines, home injection machines, extruction ship, house level machine, basement, zone of mills pe, tank, tarrajeo impermeabilizado, cemented polished polished mm., polished concrete

Raw text data extracted from CAD file:

CUADRO DE ACABADOS CASA DE MAQUINAS 2do Nivel SEGUNDO PISO NAVE DE INYECCION CONTROL RAMPAS EXTERIORES ALMACEN DE REPUESTOS CIRCULACION VEHICULOS ESCALERA 2 INGRESO VEHICULOS ESCALERA 1 PRIMER PISO CUADRO DE ACABADOS FIERRO PINTURA PINTURA ESMALTE SINTETICO EN CARPINTERIA METALICA CRISTAL TEMPLADO 8 mm, ACCESORIOS DE ALUMINIO PINTURA LATEX ACRILICA 1ra-A PINTURA OLEO MATE EN MUROS ESPEJO CORRIDO CRISTALES PASAMANOS DE ACERO INOXIDABLE SATINADO d 2" CON BALAUSTRES d 1 1/2" CRISTAL TEMPLADO 10 mm, ACCESORIOS DE ALUMINIO PUERTAS CONTRAPLACADAS CON MDF 9mm ACABADO CON PINTURA ACRILICA MAD. CARPINTERIA C./RASO-F.C.R. TARRAJADO Y PINTADO AL LATEX ACABADO CON PINTURA ESMALTE DRYWALL PUERTA METALICA REJAS TARRAJEO IMPERMEABILIZADO PLANCHA DE ETERNIT TRANSPARENTE CONTRAZOCALO CEMENTO PULIDO h= 0.10 VINILICO COLOR, h= 0.10 CEMENTO IMPERMEABILIZADO h= P/T CERAMICO .30x.30 e=9.0 mm COLOR , h= P/T ZOCALO TARRAJEO FROTACHADO, PARA PINTADO O ESTUCADO TARRAJEO PARA ENCHAPE MUROS Y COLUMNAS CEMEMTO PULIDO BRUÑADO h= 100 mm. CEMENTO IMPERMEABILIZADO VINILICO EN ROLLO CON BASE BLANDA e= 3.25 mm. CERAMICO DE .30x.30 ó .33x.33 TRANSITO INTENSO PISOS ACABADOS N° DE AMBIENTE PARTIDAS CAPA ASFALTICA PARA PISTA VEHICULAR COBERTUA DE PRECOR TIPO TR-4 ó SIMILAR ESCALERA DE FIERRO TIPO GATO DE d 1 1/2" 101 102 103 104 INGRESO PUBLICO 105 106 VEREDA PEATONAL 107 CASA DE MAQUINAS 108 CTO TABLERO DISTRIBUCION 109 110 CTO SUB ESTACION 111 SH. VARONES 112 SH. MUJERES 113 OFICINA DE SUPERVICION 114 115 116 CASA DE MAQUINAS 117 SH 118 CASA MAQUINAS DE INYECCION 119 NAVE DE EXTRUCCION 120 CASA DE MAQUINAS 2do Nivel 201 202 SOTANO ZONA DE MOLINOS PE CISTERNA 01 02 TARRAJEO IMPERMEABILIZADO CEMEMTO FROTACHADO BRUÑADO h= 100 mm. CEMENTO PULIDO h= 0.30

Language	Spanish
Drawing Type	Block
Category	Calculations
Additional Screenshots
File Type	dwg
Materials	Aluminum, Concrete, Glass, Steel, Wood
Measurement Units
Footprint Area
Building Features	Car Parking Lot
Tags	autocad, block, box, boxes, DWG, finished, industrial
