Finished Flat DWG Block for AutoCAD

Finished Flat DWG Block for AutoCAD

You can see the planes finished a department of 280 m2; It includes symbols and specifications of all interior and exterior wall finishes; floors; baseboards and ceiling. The plane is shown to 1:50 scale.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

copilco, cuauhtemoc, victory, loreto, town hall, calle altamirano, loreto, priv.victoria, River Walk, priv relox, av insurgents, the other band, av. revolution, av. Magdalena river, southern axis, joaquin gallo, cjon of the other band, relox, av. insurgentes sur, dinning room, receiver, toilet, washed, kitchen, bath, stay, bath, terrace, breakfast area, bedroom, balcony, bedroom, master bedroom, access, saved white, closet, dressing room, trash bins, spit, cupboard, study, dressing table, not flat, date:, of finishes, elaborated:, flat:, tania miranda alanis, key:, departmental floor type, specifications table of finishes, ceiling finishes, finished in zoclos, wall finishes, floor finishes, Specifications, vinyl paint brand comex color finish applied with roller three hands over flat white cement., ceramic coating on wall model brown mm of dimensions cm placed with cement white crest mark., Porcelain coating in wall model black color mm Dimensions: cm placed with white cement crest mark., porcelain coating in wall model color gray pulpis mm of dimensions: cm placed with white cement brand crest., ceramic coating on wall model white mm Dimensions: cm placed with white cement crest mark., coating on porcelain floor polished finish model bari color white mm in dimensions cm placed with white cement brand crest equivalent in quality.

Raw text data extracted from CAD file:

L COPILCO CUAUHTEMOC VICTORIA LORETO AYUNTAMIENTO CALLE ALTAMIRANO LORETO PRIV.VICTORIA PASEO DEL RIO PRIV RELOX AV INSURGENTES LA OTRA BANDA AV. REVOLUCIÓN AV. RIO MAGDALENA EJEVIAL 10-A SUR JOAQUIN GALLO CJON DE LA OTRA BANDA RELOX AV. INSURGENTES SUR COMEDOR RECIBIDOR TOILET LAVADO COCINA BAÑO ESTANCIA BAÑO TERRAZA DESAYUNADOR RECÁMARA 1 BALCÓN RECÁMARA 2 RECÁMARA PRINCIPAL ACCESO GUARDADO DE BLANCOS CLÓSET CLÓSET CLÓSET CLÓSET VESTIDOR VESTIDOR VESTIDOR CONTENEDORES DE BASURA ASADOR ALACENA ESTUDIO TOCADOR 11.5 23 11.5 9 \A1;0.10 \A1;0.10 No DE PLANO 01 \T0.85;ESCALA:\H2x; 1:50 FECHA: \H2x;\T0.75;MAYO-2015 \T0.95;PLANO DE ACABADOS ELABORÓ: PLANO: \T0.95;Arq. Tania Miranda Alanis ACA-01 CLAVE: G H I 11 12 5 5 5 5 PLANTA DE DEPARTAMENTO TIPO TABLA DE ESPECIFICACIONES DE ACABADOS ACABADOS EN PLAFONES ACABADOS EN ZOCLOS ACABADOS EN MUROS ACABADOS EN PISOS ESPECIFICACIONES PINTURA VINÍLICA MARCA COMEX COLOR "PIÑÓN" ACABADO MATE, APLICADO CON RODILLO A TRES MANOS SOBRE APLANADO DE CEMENTO BLANCO. R-1 R-2 R-3 R-4 R-5 RECUBRIMIENTO CERÁMICO EN MURO MODELO "INFINITY" COLOR MARRÓN 15 mm DE ESPESOR, DIMENSIONES 30 X 90 cm COLOCADO CON CEMENTO BLANCO MARCA CREST. RECUBRIMIENTO PORCELANIZADO EN MURO MODELO "PIZARRA" COLOR NEGRO 20 mm DE ESPESOR, DIMENSIONES: 29.5 X 59.5 cm COLOCADO CON CEMENTO BLANCO MARCA CREST. RECUBRIMIENTO PORCELANIZADO EN MURO MODELO "KALI" COLOR GRIS PULPIS 20 mm DE ESPESOR, DIMENSIONES: 30 X 60 cm COLOCADO CON CEMENTO BLANCO MARCA CREST. RECUBRIMIENTO CERÁMICO EN MURO MODELO "EFIR" COLOR BLANCO 15 mm DE ESPESOR, DIMENSIONES: 45 X 90 cm COLOCADO CON CEMENTO BLANCO MARCA CREST. P-1 RECUBIRMIENTO EN PISO PORCELANIZADO ACABADO PULIDO MODELO BARI COLOR BLANCO 20 mm DE ESPESOR, EN DIMENSIONES 60 X 60 cm COLOCADO CON CEMENTO BLANCO MARCA CREST O EQUIVALENTE EN CALIDAD.

Language	Spanish
Drawing Type	Block
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Other
Measurement Units
Footprint Area
Building Features
Tags	autocad, block, dach, dalle, department, DWG, escadas, escaliers, exterior, finished, finishes, flat, Housing, includes, interior, lajes, mezanino, mezzanine, PLANES, platte, reservoir, roof, slab, specifications, stair, symbolism, symbols, telhado, toiture, treppe, wall
