Firewall DWG Block for AutoCAD

Firewall DWG Block for AutoCAD

Firewall – wood ceiling

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

fire wall detail, scale, truss pine, coastal pine, zinc cover standard wave, brick fiscal type, rope position, cm. of thickness, exterior stucco, smooth zinc lining mm. thickness

Raw text data extracted from CAD file:

\A1;0.80 \A1;0.20 \A1;0.50 Detalle Muro Cortafuego 0.7999999999999968 F - 120 Escala 1 : 20 Cercha Pino Costanera Pino 2" x 2" Cubierta Zinc Onda Standard 5 0.2000000000000028 Ladrillo Tipo Fiscal Posición Soga 2,5 cm. de Espesor Estuco Exterior Forro Zinc Liso 0,5 mm. Espesor

Language	Spanish
Drawing Type	Block
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Wood
