Hostel, Unisex Hostel, Students Hostel, Students Residence 2D DWG Plan for AutoCAD
Plan, elevation and sectional view of hostel or students residence. The floor plan has following areas clearly identified – projection room, cabin, men and women healthcare rooms, men and women baths, waste area, machine room, rest room, pantry, cellar, men and women dormitory- each dormitory has 25 beds. The total foot print area is approximately 3280 sq meters.
| Language | Spanish |
| Drawing Type | Plan |
| Category | Hospital & Health Centres |
| Additional Screenshots |
  |
| File Type | dwg |
| Materials | |
| Measurement Units | Metric |
| Footprint Area | 2500 - 4999 m² (26909.8 - 53808.7 ft²) |
| Building Features | Car Parking Lot, Garden / Park |
| Tags | DWG, elevations, residence, section |
