Imhoff Tank DWG Block for AutoCAD

Imhoff Tank DWG Block for AutoCAD

Imhoff tank for water purification served as an unconventional system – Ground – Court

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Min, section, Valve chamber, Digestion chamber, Min, Gas venting point, Cleaning mouth, scale, Sludge pipe, Sediment chamber., plant, Valve chamber, Input channel, entry, deflector, effluent, dump, Foam deflector, scale, Sludge pipelines

Raw text data extracted from CAD file:

0,46m 0,50m 0,46m 0,50m 1,81m 0,40m 0,13m 0,50m 1,00m 2,00m 0,15m 1,62m 0,10m 0,41m 1,62m 4,76m 0,15m min 0.15m 0,55m 1,62m 1,00m 0,50m 0,46m SECCION A-A 5 5 5 5 5 5 5 5 5 5 Cámara de Válvulas Cámara de Digestión 5 5 5 5 5 5 5 min 0.15m Punto de venteo de gases Boca de Limpieza Escala 1:25 Tuberia para Lodos d 200mm Cámara de Sediment. PLANTA 5 5 5 Cámara de Válvulas 5 5 Canal de Entrada Entrada Deflector Efluente Vertedero Deflector de Espumas A A Escala 1:25 Tuberías de Conducción de Lodos

Language	Spanish
Drawing Type	Block
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials
Measurement Units
Footprint Area
Building Features
Tags	autocad, block, court, DWG, einrichtungen, facilities, gas, gesundheit, ground, imhoff, imhoff tank, l'approvisionnement en eau, la sant, le gaz, machine room, maquinas, maschinenrauminstallations, provision, purification, served, system, tank, wasser bestimmung, water
