Industrial Fire Monitor Detail Drawing with 360° rotation Range

Comprehensive technical detail drawing of an industrial fire monitor assembly designed for firefighting applications. The drawing illustrates the monitor from multiple elevations showing its 360° continuous horizontal rotation capability and vertical adjustment range of approximately 135° with a 4° minimum angle. Key components include the main barrel, discharge nozzle, swivel joints, mounting flange, and control handles for precise directional control. The design features threaded connections and integrated fasteners for secure installation. The monitor appears to be constructed with standardized fittings and incorporates a sealed bearing assembly at the rotation point to ensure smooth operation under high-pressure conditions. Connection dimensions appear to be approximately 3-4 inches in diameter, suitable for high-volume water flow applications typical in industrial firefighting systems. The flanged base mount provides stability during operation while accommodating the significant reaction forces generated during discharge.
