Industrial Warehouse Master Plan with Fire Safety Infrastructure

Overview

This master site plan presents the layout of a large-scale industrial warehouse project located in Tan Khai, Hon Quan District, Binh Phuoc Province. The drawing shows two primary warehouse structures (labeled Warehouse 1 and 2) within a comprehensive site development plan that includes fire safety infrastructure and circulation elements.

Site Specifications

– Total site area: 145,585.5 m² – Industrial land area: 102,654.5 m² – Total built area: 37,089.94 m² – Warehouse 1 area: 17,835.94 m² – Warehouse 2 area: 19,200 m²

Fire Safety Features

The plan incorporates comprehensive fire protection systems including: – Underground water tank (9m × 30m × 3m depth) – Fire pump station (6m × 9m) – Four dedicated fire engine parking areas (3.5m × 47m each) – Emergency exit doors strategically placed throughout both warehouses

Site Circulation

The site layout shows concrete roadways with detailed cross-sections featuring: – 150mm thick M250 concrete surface layer – 200mm crushed stone sub-base – 200mm compacted soil base The design incorporates specific slope, overall, gradients (10-15%) for drainage and access ramps. The site connects to Provincial Road 756B (Tan Khai – Tan Quan) with multiple access points.
