Isolated Footing Triditec DWG Section for AutoCAD

Isolated Footing Triditec DWG Section for AutoCAD

Isolated footing triditec – Plant – Section

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

anchored with var, doubles in, polystyrene, tridipane, mortar, in both ways, rods, detail of, plant, stirrups, with rods, castle, by armed side, rods, in both ways, with rod in, wall anchor, rods, poor concrete, template, mortar, tridipane, polystyrene, raised, isolated footing

Raw text data extracted from CAD file:

\A1;1.00 \A1;0.20 \A1;0.03 \A1;1.00 \A1;0.50 \A1;1.00 \A1;0.50 0.50 1.00 ANCLADO CON VAR #3 DOBLES EN "U" 2.5" DE POLISTIRENO TRIDIPANEL CAL.12.5 1.5" DE MORTERO EN AMBOS SENTIDOS VARILLAS #4 @20cm DETALLE "D-41" DE PLANTA ESTRIBOS #2 @20cm CON 4 VARILLAS #3 Y CASTILLO 22cm POR LADO ARMADO VARILLAS #4 @20cm EN AMBOS SENTIDOS CON VARILLA #3 en "u" ANCLAJE DE MURO 4 VARILLAS #3 0.03 0.20 CONCRETO POBRE PLANTILLA DE 1.5" DE MORTERO TRIDIPANEL CAL.12.5 2.5" DE POLISTIRENO 0.50 1.00 1.00 ALZADO ZAPATA AISLADA

Language	Spanish
Drawing Type	Section
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete
Measurement Units
Footprint Area
Building Features
Tags	adobe, autocad, bausystem, construction system, covintec, DWG, earth lightened, erde beleuchtet, footing, isolated, losacero, plant, plywood, section, sperrholz, stahlrahmen, steel framing, système de construction, terre s
