PLANT E isometry INS. BATH

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

registry, Ventilates, Elbow, Trap with log, Elbow, discharge, Ventilates, Elbow, discharge, Ventilates, discharge, Sale collector, Ventilates, simple, Elbow, simple, Simple with reduction, simple, Health isometry, Sanitary block, Esc:, Gas hydraulics, Sanitary facilities plan, Autonomous university of new lion faculty of architecture

Raw text data extracted from CAD file:

2,78 1,68 5 <> REGISTRO VENTILA 4" CODO DE 45° 2" TRAMPA 2" CON REGISTRO CODO DE 45° 4" DESCARGA 4" VENTILA 4" VENTILA 4" CODO DE 45° 2" CODO DE 90° 2" DESCARGA 4" VENTILA 4" DESCARGA 4" SALE A COLLECTOR VENTILA 2" "T" SENCILLA 2" "T" SENCILLA 4" "T" SENCILLA 4" CODO DE 45° 4" CODO DE 90° 4" "Y" SENCILLA 4" "Y" SENCILLA CON REDUCCION "T" SENCILLA 4" ISOMETRIA SANITARIA BLOCK SANITARIO 1:5 Esc: INSTALACIONES HIDRAULICAS Y GAS PLANO DE : INSTALACIONES SANITARIAS UNIVERSIDAD AUTÓNOMA DE NUEVO LEÓN FACULTAD DE ARQUITECTURA 0.00 2.00 1.00 0.50 1.50
