Mechanical Bracket Cross-Section with R40 Eyelet Connection

This detailed cross-section depicts a specialized mechanical bracket component with multiple radiused features and precision-bored holes. The part features a prominent top eyelet with R40 dimensions, designed for pinned connection applications. The overall height measures 246mm with a width of 168mm at the base. The component includes several critical radius transitions (R5, R6, R14, R26) that distribute stress effectively between sections. The central mounting region contains a 52mm bore with intricate geometry, while the base provides a stable 100mm mounting surface with 24mm thickness. Manufacturing would require careful consideration of radii transitions, particularly where the R40 eyelet connects to the main body through an R94 transition arc. This design appears optimized for load transfer in mechanical linkage applications where both vertical and angular forces must be accommodated.
