Mezzanin Amble Ceramic Block DWG Section for AutoCAD

Mezzanin Amble Ceramic Block DWG Section for AutoCAD

Section mezzanine , amble ceramic block

Drawing labels, details, and other text information extracted from the CAD file (Translated from Galician):

layer thickness compression cm, ceramic block of ceiling, pre-stressed concrete rod, double layer of asphaltic felt, chained beam lintel, bearing ceramic block, layer thickness compression cm, ceramic block of ceiling, pre-stressed concrete rod, double layer of asphaltic felt, steel mesh, ceramic block, telgoport, chained beam lintel, bearing ceramic block

Raw text data extracted from CAD file:

Capa de compresión espesor 4 a 7 cm Bloque cerámico de techo 11x38x25 Vigueta de hormigon pretensado Doble capa de fieltro asfáltico Viga de encadenado (Ladrillo Dintel 18x19x25) Bloque cerámico portante 18x19x33 Capa de compresión espesor 4 a 7 cm Bloque cerámico de techo 11x38x25 Vigueta de hormigon pretensado Doble capa de fieltro asfáltico Malla de acero Bloque cerámico 8x18x33 Telgoport Viga de encadenado (Ladrillo Dintel 18x19x25) Bloque cerámico portante 18x19x33
