In the preparation and / or exploitation of a work is done inside the mine with a drilling machine to drill a section of 8 m wide by 8 m high;

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

loading of boreholes, boreholes loaded with examon, bait, clay block, carmex, examon, standard for perforation mesh of a front, new, sheet, cia. mining construction, u.p. mine hope, area of ​​responsibility, proc:, mine, mine, procedure, revised, involved sections nos, iii, executive committee, drawn :, dept. mine, approval:, superintendent, area manager, chief of security

Raw text data extracted from CAD file:

1.50 m. 80 cm. 2.40 m. 0.80 m. 0.80 m. 40 cm. 80 cm. 2.40 m. 30 cm. 30 cm. 50 cm. 50 cm. Taladro de Alivio = 02 Arranque = 04 Ayudas = 12 Cuadradores = 04 Alzas = 05 Arrastres = 05 d64 mm. d38 mm. Longitud de taladro 8' Carguío de taladros de las Alzas Taladros cargados con Examon 1.50 m. 80 cm. Cebo Dinamita de 7/8" x 7" 45% Carrizo 30 cm. (Espaciador) Taco de Arcilla Carmex Carmex Taco de Arcilla Cebo Dinamita de 1 1/8" x 7" 65% EXAMON 2.40 m. 0.80 m. 0.80 m. 40 cm. 80 cm. 2.40 m. 30 cm. 30 cm. 50 cm. 50 cm. ESTANDAR PARA MALLA DE PERFORACION DE UN FRENTE SECCION 8' x 8' NUEVO ( 2 - 2 ) HOJA CIA. MINING. CONSTRUCTION U.P. MINA ESPERANZA AREA DE RESPONSABILIDD PROC: MINAS MINA 001 PROCEDIMIENTO REVISADO SECCIONES INVOLUCRADAS NOSA I II III IV V COMITE DIRECTIVO ELABORADO: DPTO. MINA APROBACION: FECHA: AGO-2010 SUPERINTENDENTE JEFE DE AREA JEFE DE SEGURIDAD VERSION N° 2 X
