Monopolo Tower DWG Detail for AutoCAD

Monopolo Tower DWG Detail for AutoCAD

Antenna monopolo for cellular telephony with details

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

painted monopole white, feeders entry, enclosure chain, of copper lands of, feeders entry, niche for rush switch, cut, of copper lands of, rows of barbed wire, of copper lands of, hollow block wall joined with sand cement mortar prop. top with concrete dala total height on level of gravel bed add rows of wire to see detail in exterior interior finish planes both with one hand application of vinyl sealer comex two of vinyl paint in white line quality comex., reinforced concrete floor with thick electrowelded mesh, foundation projection

Raw text data extracted from CAD file:

X N.P.T.±0.00 \A1;150 \A1;200 \A1;R60 \A1;100 \A1;200 \A1;200 \A1;160 150.0 N.T.T.+30.25 MONOPOLO DE 30M PINTADO DE COLOR BLANCO ENTRADA DE FEEDERS 200.0000000000142 CADENA DE CERRAMIENTO \A1;BARRA DE TIERRAS DE COBRE DE 36"X2"X\S3#8;" ENTRADA DE FEEDERS N.T.D.+0.60 NICHO PARA ACOMETIDA E INTERRUPTOR ESC.1:75 CORTE A-A' N.T.F.C.+0.15 \A1;BARRA DE TIERRAS DE COBRE DE 20"X6"X\S1#4;" 3 1 2 6 5 4 7 5 100.0 3 HILERAS DE ALAMBRE DE PUAS \A1;BARRA DE TIERRAS DE COBRE DE 36"X2"X\S3#8;" 200.0 N.T.M.+3.20 MURO DE BLOCK HUECO DE 15x20x40cms JUNTEADO CON MORTERO CEMENTO ARENA PROP. 1:4 REMATAR CON DALA DE CONCRETO h=20cm, ALTURA TOTAL 3.10mts. SOBRE NIVEL DE CAMA DE GRAVA AGREGAR 3 HILERAS DE ALAMBRE DE PUAS, VER DETALLE EN PLANOS A-2 Y ESTRUCTURALES, ACABADO INTERIOR APARENTE, EXTERIOR APLANADO, AMBOS CON APLICACION DE UNA MANO DE SELLADOR VINILICO 5x1 COMEX Y DOS DE PINTURA VINILICA EN COLOR BLANCO LINEA PRO-MIL CALIDAD COMEX. FIRME DE CONCRETO f'c=150 Kg/cm2 ARMADO CON MALLA ELECTROSOLDADA 6X6/4X4 DE 10cm DE ESPESOR PROYECCION DE CIMENTACION 8 200.0 N.C.R.A.+30.00 159.9999999999994 N.T.P.+33.35 N.B.R.±0.00 28.00

Language	Spanish
Drawing Type	Detail
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials	Concrete
Measurement Units
Footprint Area
Building Features
Tags	antenna, autocad, cellular, DETAIL, details, DWG, einrichtungen, facilities, gas, gesundheit, l'approvisionnement en eau, la sant, le gaz, machine room, maquinas, maschinenrauminstallations, provision, telephony, tower, wasser bestimmung, water
