Mounting Bracket Detail Drawing for Electronic enclosure Support
ADVERTISEMENT
ADVERTISEMENT
Precision-engineered mounting bracket for electronic component enclosure with four mounting holes positioned at each corner. The design features serrated edges along the top and bottom surfaces for heat dissipation or component engagement. The bracket has a square profile with flanged edges that extend outward for mounting stability. All dimensions are precisely defined at 1:1 scale, ensuring accurate manufacturing. The symmetrical design allows for uniform load distribution when installed. The mounting holes appear to be designed for standard fasteners and are positioned to provide optimal structural integrity when supporting the intended electronic components.
| Language | Spanish |
| Drawing Type | Detail |
| Category | Electronic Components & Devices |
| Additional Screenshots | |
| File Type | dwg |
| Materials | Aluminum, Steel |
| Measurement Units | Metric |
| Footprint Area | 1 - 9 m² (10.8 - 96.9 ft²) |
| Building Features | |
| Tags | component mounting, electronic enclosure, fastener detail, metal bracket, mounting bracket, serrated bracket, support pletina |
