Multi-Level Residential Tower Floor Plans with structural Details

A1 Block Mixed-Use Residential Tower Project

This comprehensive set of architectural and structural drawings details a 13-story residential tower (A1 Block) located in Kartal-Yakacik district. The drawings include multiple floor plans, elevations, sections, and structural details with the following key specifications:

Building Configuration:
– 13 above-ground floors plus 2 basement levels
– Ground floor features commercial spaces (3 retail units ranging from 55m² to 482m²)
– Upper floors contain various apartment configurations (1+1A, 1+1B, 1+1C, and 2+1 layouts)
– Typical floor-to-floor height: 3.0m
– Total height: approximately 45.4m from ground level (+52.50) to roof parapet (+97.90)

Technical Details:
– Reinforced concrete structure with 20cm thick floor slabs
– Multiple structural elements specified (SA1.01-SA1.17 and PA1.01-PA1.06)
– Core circulation featuring main stairwell, fire escape stairs, and elevator shafts
– Roof includes mechanical equipment, 1% slope drainage system, and maintenance access
– HVAC provisions with designated exterior unit locations on balconies

Apartment units feature standardized doors (P01:90/200cm, P02:150/200cm, P03:220/200cm, P08:240/240cm) and include balconies, bathrooms with suspended ceilings, and kitchen ventilation. The structure employs a grid system with axial dimensions clearly marked for construction alignment. Foundation details and basement levels accommodate parking facilities below grade.
