NICHE CONSTRUCTION MEASURES TO HOUSE BASE MEASUREMENT MEASUREMENT M – 5 of 7 TERMINALS 200 or 100 AMP

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

concrete slab cms. thickness not. cm. ace, chain of arches in concrete, npt, acrylic visor made of aluminum with holder

Raw text data extracted from CAD file:

\A1;0.90 \A1;0.60 \A1;0.60 \A1;2.10 \A1;1.10 \A1;0.20 \A1;0.15 \A1;0.20 \A1;2.10 \A1;0.20 \A1;1.10 \A1;0.10 \A1;0.60 \A1;0.10 \A1;0.60 \A1;0.60 (CD-1) \W8.54086; LOSA DE CONCRETO \W8.74562; f'c=200 kg/cm2, \W8.54562; 10 cms. ESPESOR \W8.09324; Var No. 3 @ 15 cm. A.S 5 5 5 5 5 5 CADENA DE DESPLANTE \W0.89732; (CD-1) \W4.87884; ARMEX 15 x 20 cm CONCRETO f´c: 200 kg/cm² 5 5 (CD-1) NPT +/- 0.00 (CD-1) 5 5 5 5 5 5 5 5 \W8.80276; MIRILLA ACRILICA \W8.64086; HECHA A BASE DE \W9.01705; ALUMINIO CON \W8.93133; PORTACANDADO

Language	Spanish
Drawing Type	Block
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials	Aluminum, Concrete
