Residential Floor Plan with Multi-Room Layout and Wall Partitions

This drawing shows a partial floor plan for a residential space featuring multiple rooms with varying dimensions. The main section spans 25′-5″ in width, with an adjacent area measuring 28′-5″ wide, suggesting a potential extension or separate wing. Interior wall partitions delineate several distinct spaces, with one particular area measuring 16′-3″ by 10′-6″. The layout appears to use a modular approach with rectangular spaces arranged in a practical configuration. The drawing uses the ‘wall’ layer to differentiate structural elements from dimensions. This floor plan employs standard framing techniques with walls that would typically be 2×4 or 2×6 construction. The rectangular arrangement optimizes space utilization while maintaining standard room proportions for residential functionality.
