DESIGN PROFILE AND SECTIONS

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

ing. jose francisco ortiz adame, general director of o.p.d. c.i.c.a.e.g., road: el carmen – miahuichan, region :, project data :, c.p. c.zeferino torreblanca galindo, state governor, section, concept :, road type :, project speed :, base thickness :, maximum curvature :, maximum slope :, carriageway width :, governor slope :, crown width :, characteristics, plane :, file :, review :, I lift :, date :, top. moises sanchez towers, num:, dimensions:, scale :, graphics :, project :, projects department :, ing. cipriano hilario serrano, director of works :, in meters., warrior, existing road, project axis, right of way, entrance, exit, curve box, curve, delta, radio, arch, stan, rope, course rope , type, material, factor, abundance, compaction, ordinates, mass curve, embankment, cut, subgrade, terrain, volume, thickness, elevation, profile, board for comp channels. a, drainage works, characteristics of the section, demolitions, structural steel, reinforcing steel, specifications of the project, road type project speed crown width folder thickness base thickness maximum curvature slope governor maximum slope, construction profile, scales, concepts, concrete, cyclopean , mass, excavations, masonry, zampeado, material c, dry, material b, material a, walls, tubes, unit, in this plane, excavation, tons, of terraces, of pavements, natural in the, of the cuts, exhausts in , in embankments, of the laying of, of elevation of, of the enlargement, of the filling to form, mat. no comp., subgrade layer, built on, of refining., with or without wedge, of embankments, existing, embankments, area of, of the bed, of the terrain, in cuts, slopes, of lacorona, superior of, of the layer , material product of the loans, earthworks, quantities of work, landslides, compaction, geometry in the excavation, material product of the cuts, laterals, geometric in the loan, loans, the strip of, bank, inside, despalme, total, down subgrade, cuts a, b, c, steps, formaciony, mat. tapped, mat. wasted, extension of cuts, crown recesses, additional cutting, compaction, vol.geom., bandeado, department of studies and projects, survey :, projected :, road: the conception – quiahuitlatzala, pavement structure, folder, existing terraceria , natural terrain, project subgrade line, type section, base, path: copala – atrixco, top. bulmaro prieto, road: la concepcion – quiahuitlatzala, axis construction, side, distance, bearing, coordinates, est

Raw text data extracted from CAD file:

1 -4.36% +4.36% Y=1,858,900 Y=1,858,800 Y=1,858,600 Y=1,858,500 Y=1,858,400 Y=1,858,200 Y=1,858,100 X=526,100 ING. JOSE FRANCISCO ORTIZ ADAME DIRECTOR GENERAL DEL O.P.D. C.I.C.A.E.G. DE ESTACION: KM 0+000 AL 5+680 CAMINO: EL CARMEN - MIAHUICHAN REGION: DATOS DEL PROYECTO: C.P. C.ZEFERINO TORREBLANCA GALINDO GOBERNADOR DEL ESTADO C 40 KM/HR. DEL TRAMO CONCEPTO: CAMINO TIPO: VELOCIDAD DE PROYECTO: 30° 20 CMS. 6 MTS. 8.00% 6.0 % ESPESOR DE BASE: CURVATURA MAXIMA: PENDIENTE MAXIMA: ANCHO DE CALZADA: PENDIENTE GOBERNADORA: ANCHO DE CORONA: 7 MTS. CARACTERISTICAS PLANO: ARCHIVO: REVISO: LEVANTO: FECHA: TOP. MOISES SANCHEZ TORRES SEPTIEMBRE /2008 NUM: ACOTACIONES : ESCALA: GRAFICOS: PROYECTO: DEPARTAMENTO DE PROYECTOS: ING. CIPRIANO HILARIO SERRANO DIRECTOR DE OBRAS: PLANTA (ALINEAMIENTO HORIZONTAL) EN METROS. G U E R R E R O CAMINO EXISTENTE EJE DE PROYECTO DERECHO DE VIA SUB TRAMO: DEL KM 0+000 AL KM 5+680 1:2000 X=526,100 0+000.00 0+020.00 0+040.00 0+060.00 0+080.00 0+100.00 0+120.00 0+140.00 0+160.00 0+180.00 0+200.00 0+220.00 0+240.00 0+260.00 0+280.00 0+300.00 0+320.00 0+340.00 0+360.00 0+380.00 0+400.00 0+420.00 0+440.00 0+460.00 0+480.00 0+500.00 0+520.00 0+540.00 0+560.00 0+580.00 0+600.00 0+620.00 0+640.00 0+660.00 0+680.00 0+700.00 0+720.00 0+740.00 0+760.00 0+780.00 0+800.00 0+820.00 0+840.00 0+860.00 0+880.00 0+900.00 0+920.00 0+940.00 0+960.00 0+980.00 1+000.00 1+020.00 1+040.00 1+060.00 1+080.00 1+100.00 1+120.00 1+140.00 1+160.00 1+180.00 1+200.00 1+220.00 1+240.00 1+260.00 1+280.00 1+300.00 1+320.00 1+340.00 1+360.00 1+380.00 1+400.00 1+420.00 1+440.00 1+460.00 1+480.00 1+500.00 1+520.00 1+540.00 1+560.00 1+580.00 1+600.00 1+620.00 1+640.00 1+660.00 1+680.00 1+700.00 1+720.00 1+740.00 1+760.00 1+780.00 1+800.00 1+820.00 1+840.00 1+860.00 1+880.00 1+900.00 1+920.00 1+940.00 Y=800 Y=900 Y=1,000 Y=1,100 Y=1,200 Y=1,300 Y=1,400 Y=1,500 Y=1,600 Y=1,700 Y=1,800 Y=1,900 Y=2,000 Y=2,100 Y=2,200 Y=2,300 Y=2,400 Y=2,500 Y=2,600 Y=2,700 Y=2,800 X=2,900 X=3,000 X=3,100 X=3,200 X=3,300 X=3,400 X=3,500 X=3,600 X=3,700 X=3,800 X=3,900 X=4,000 X=4,100 X=4,200 X=4,300 X=4,400 X=4,500 D = 6°4'0.00" der ST = 20.241 PI = 0+163.49 Gc = 3°0'0.00" Lc = 40.444 Rc = 381.972 Sc = 2.50% Ac = 0.40 Le entrada = 22.40 Le salida = 22.40 PC=0+143.25 PT=0+183.70 D = 4°46'0.00" der ST = 23.764 PI = 0+280.50 Gc = 2°0'0.00" Lc = 47.500 Rc = 572.958 Sc = 2.00% Ac = 0.30 Le entrada = 10.00 Le salida = 10.00 PC=0+256.73 PT=0+304.23 D = 12°14'0.00" izq ST = 20.467 PI = 0+347.19 Gc = 6°0'0.00" Lc = 40.778 Rc = 190.986 Sc = 4.50% Ac = 0.60 Le entrada = 7.90 Le salida = 7.90 PC=0+326.72 PT=0+367.50 D = 14°10'0.00" izq ST = 20.342 PI = 0+645.58 Gc = 7°0'0.00" Lc = 40.476 Rc = 163.702 Sc = 5.10% Ac = 0.70 Le entrada = 22.40 Le salida = 22.40 PC=0+625.24 PT=0+665.72 D = 27°30'0.00" der ST = 20.029 PI = 0+769.64 Gc = 14°0'0.00" Lc = 39.286 Rc = 81.851 Sc = 7.90% Ac = 1.10 Le entrada = 25.43 Le salida = 25.43 PC=0+749.61 PT=0+788.89 D = 26°26'0.00" der ST = 20.702 PI = 0+856.74 Gc = 13°0'0.00" Lc = 40.667 Rc = 88.147 Sc = 7.60% Ac = 1.00 Le entrada = 24.44 Le salida = 24.44 PC=0+836.04 PT=0+876.71 D = 12°10'0.00" der ST = 20.354 PI = 0+934.40 Gc = 6°0'0.00" Lc = 40.556 Rc = 190.986 Sc = 4.50% Ac = 0.60 Le entrada = 19.00 Le salida = 19.00 PC=0+914.04 PT=0+954.60 D = 27°46'0.00" izq ST = 21.787 PI = 1+029.99 Gc = 13°0'0.00" Lc = 42.718 Rc = 88.147 Sc = 7.60% Ac = 1.00 Le entrada = 24.44 Le salida = 24.44 PC=1+008.21 PT=1+050.92 D = 56°0'0.00" izq ST = 26.491 PI = 1+127.89 Gc = 23°0'0.00" Lc = 48.696 Rc = 49.822 Sc = 9.60% Ac = 1.50 Le entrada = 30.71 Le salida = 30.71 PC=1+101.40 PT=1+150.09 D = 17°4'0.00" der ST = 21.492 PI = 1+302.09 Gc = 8°0'0.00" Lc = 42.667 Rc = 143.239 Sc = 5.60% Ac = 0.70 Le entrada = 22.40 Le salida = 22.40 PC=1+280.60 PT=1+323.27 D = 12°30'0.00" izq ST = 20.916 PI = 1+423.39 Gc = 6°0'0.00" Lc = 41.667 Rc = 190.986 Sc = 4.50% Ac = 0.60 Le entrada = 22.40 Le salida = 22.40 PC=1+402.48 PT=1+444.14 D = 10°40'0.00" der ST = 21.395 PI = 1+575.29 Gc = 5°0'0.00" Lc = 42.667 Rc = 229.183 Sc = 3.90% Ac = 0.50 Le entrada = 22.40 Le salida = 22.40 PC=1+553.89 PT=1+596.56 D = 31°16'0.10" der ST = 21.378 PI = 1+917.08 Gc = 15°0'0.00" Lc = 41.689 Rc = 76.394 Sc = 8.20% Ac = 1.10 Le entrada = 3.00 Le salida = 3.00 PC=1+895.71 PT=1+937.39 143.26m S 34°00'00.00" W 73.04m S 40°04'00.00" W 22.49m S 44°50'00.00" W 257.74m S 32°36'00.00" W 83.89m S 18°26'00.00" W 47.15m S 45°56'00.00" W 37.33m S 72°22'00.00" W 53.61m S 84°32'00.00" W 50.47m S 56°46'00.00" W 130.51m S 00°45'59.99" W 79.21m S 17°50'00.00" W 109.75m S 05°20'00.00" W 299.15m S 16°00'00.00" W 2.66m S 47°16'00.10" W X=3,000 CUADRO DE CURVAS CURVA DELTA RADIO ARCO STAN CUERDA Gc RUMBO CUERDA C1 06°4'0.00" 381.972 40.444 20.241 40.426 03°0'0" S 37°02'00.00" W C2 04°46'0.00" 570.952 47.500 23.764 47.486 02°0'25" S 42°27'00.00" W C3 12°14'0.00" 190.986 40.778 20.467 40.700 06°0'0" N 38°43'00.00" E C4 14°10'0.00" 163.702 40.476 20.342 40.373 07°0'0" N 25°31'00.00" E C5 27°30'0.00" 81.851 39.286 20.029 38.910 14°0'0" S 32°11'00.00" W C6 26°26'0.00" 88.147 40.667 20.702 40.307 13°0'0" S 59°09'00.00" W C7 12°10'0.00" 190.986 40.556 20.354 40.479 06°0'0" S 78°27'00.00" W C8 27°46'0.00" 88.147 42.718 21.787 42.301 13°0'0" N 70°39'00.00" E C9 56°0'0.00" 49.822 48.696 26.491 46.780 23°0'0" N 28°45'59.99" E C10 17°4'0.00" 143.239 42.667 21.492 42.509 08°0'0" S 09°18'00.00" W C11 12°30'0.00" 190.986 41.667 20.916 41.584 06°0'0" N 11°35'00.00" E C12 10°40'0.00" 229.183 42.667 21.395 42.605 05°0'0" S 10°40'00.00" W C13 31°16'0.10" 76.394 41.689 21.378 41.174 15°0'0" S 31°38'00.05" W CUADRO DE CURVAS CURVA DELTA RADIO ARCO STAN CUERDA Gc RUMBO CUERDA C1 06°4'0.00" 381.972 40.444 20.241 40.426 03°0'0" S 37°02'00.00" W C2 04°46'0.00" 570.952 47.500 23.764 47.486 02°0'25" S 42°27'00.00" W C3 12°14'0.00" 190.986 40.778 20.467 40.700 06°0'0" N 38°43'00.00" E C4 14°10'0.00" 163.702 40.476 20.342 40.373 07°0'0" N 25°31'00.00" E C5 27°30'0.00" 81.851 39.286 20.029 38.910 14°0'0" S 32°11'00.00" W C6 26°26'0.00" 88.147 40.667 20.702 40.307 13°0'0" S 59°09'00.00" W C7 12°10'0.00" 190.986 40.556 20.354 40.479 06°0'0" S 78°27'00.00" W C8 27°46'0.00" 88.147 42.718 21.787 42.301 13°0'0" N 70°39'00.00" E C9 56°0'0.00" 49.822 48.696 26.491 46.780 23°0'0" N 28°45'59.99" E C10 17°4'0.00" 143.239 42.667 21.492 42.509 08°0'0" S 09°18'00.00" W C11 12°30'0.00" 190.986 41.667 20.916 41.584 06°0'0" N 11°35'00.00" E C12 10°40'0.00" 229.183 42.667 21.395 42.605 05°0'0" S 10°40'00.00" W C13 31°16'0.10" 76.394 41.689 21.378 41.174 15°0'0" S 31°38'00.05" W 0+000.00 0+020.00 0+040.00 0+060.00 0+080.00 0+100.00 0+120.00 0+140.00 0+160.00 0+180.00 0+200.00 0+220.00 0+240.00 0+260.00 0+280.00 0+300.00 0+320.00 0+340.00 0+360.00 0+380.00 0+400.00 0+420.00 0+440.00 0+460.00 0+480.00 0+500.00 0+520.00 0+540.00 0+560.00 0+580.00 0+600.00 0+620.00 0+640.00 0+660.00 0+680.00 0+700.00 0+720.00 0+740.00 0+760.00 0+780.00 0+800.00 0+820.00 0+840.00 0+860.00 0+880.00 0+900.00 0+920.00 0+940.00 0+960.00 0+980.00 1+000.00 1+020.00 1+040.00 1+060.00 1+080.00 1+100.00 1+120.00 1+140.00 1+160.00 1+180.00 1+200.00 1+220.00 1+240.00 1+260.00 1+280.00 1+300.00 1+320.00 1+340.00 1+360.00 1+380.00 1+400.00 1+420.00 1+440.00 1+460.00 1+480.00 1+500.00 1+520.00 1+540.00 1+560.00 1+580.00 1+600.00 1+620.00 1+640.00 1+660.00 1+680.00 1+700.00 1+720.00 1+740.00 1+760.00 1+780.00 1+800.00 1+820.00 1+840.00 1+860.00 1+880.00 1+900.00 1+920.00 1+940.00 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 33 34 35 36 37 38 39 40 41 L C R=38.41 T.N.=38.60 OFF=-7.57 R=36.00 OFF=7.67 R=35.90 AREA DE CORTE = 1.50m2 AREA DE TERRAPLEN = 13.59m2 AREA DESPALME TERRAPLEN = 1.75m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.51m2 BASE = 1.52m2 CARPETA = 0.36m2 +0.96% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+740.00 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 44 45 46 47 48 49 L C R=46.75 T.N.=47.00 OFF=-4.64 R=46.88 OFF=4.53 R=46.24 AREA DE CORTE = 1.86m2 AREA DE TERRAPLEN = 0.56m2 AREA DESPALME TERRAPLEN = 0.30m2 AREA DESPALME CORTE = 1.55m2 SUBRASANTE = 2.58m2 BASE = 1.54m2 CARPETA = 0.36m2 -2.00% 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+940.00 55 50 45 40 35 30 TIPO DE MATERIAL FACTOR DE ABUNDAMIENTO FACTOR DE COMPACTACION ORDENADAS DE LA CURVA MASA TERRAPLEN CORTE TERRAPLEN CORTE SUBRASANTE TERRENO VOLUMEN ESPESOR ELEVACION ESCALA HORIZONTAL 1 : 2000 ESCALA VERTICAL 1 : 200 PERFIL -4.80 % en 10.00m PCV=0+009.99 Elev=43.12 PIV=0+019.99 Elev=42.64 PTV=0+029.99 Elev=42.31 -3.30 % en 10.00m PCV=0+040.00 Elev=41.98 PIV=0+060.00 Elev=41.32 PTV=0+080.00 Elev=41.18 -0.70 % en 40.00m PCV=0+120.00 Elev=40.90 PIV=0+140.00 Elev=40.76 PTV=0+160.00 Elev=41.00 +1.20 % en 40.00m PCV=0+200.00 Elev=41.48 PIV=0+220.00 Elev=41.72 PTV=0+240.00 Elev=42.68 +4.80 % en 60.00m PCV=0+300.00 Elev=45.56 PIV=0+320.00 Elev=46.52 PTV=0+340.00 Elev=46.62 +0.50 % en 20.00m PCV=0+360.00 Elev=46.72 PIV=0+380.00 Elev=46.82 PTV=0+400.00 Elev=46.12 -3.50 % en 40.00m PCV=0+440.00 Elev=44.72 PIV=0+460.00 Elev=44.02 PTV=0+480.00 Elev=42.86 -5.80 % en 20.00m PCV=0+500.00 Elev=41.70 PIV=0+520.00 Elev=40.54 PTV=0+540.00 Elev=39.82 -3.60 % en 20.00m PCV=0+560.00 Elev=39.10 PIV=0+580.00 Elev=38.38 PTV=0+600.00 Elev=38.40 +0.10 % en 120.00m PCV=0+720.00 Elev=38.52 PIV=0+740.00 Elev=38.54 PTV=0+760.00 Elev=38.06 PCV=0+760.00 Elev=38.06 PIV=0+780.00 Elev=37.58 PTV=0+800.00 Elev=37.64 +0.30 % en 20.00m PCV=0+820.00 Elev=37.70 PIV=0+840.00 Elev=37.76 PTV=0+860.00 Elev=38.44 +3.40 % en 40.00m PCV=0+900.00 Elev=39.80 PIV=0+920.00 Elev=40.48 PTV=0+940.00 Elev=40.60 +0.60 % en 80.00m PCV=1+020.00 Elev=41.08 PIV=1+040.00 Elev=41.20 PTV=1+060.00 Elev=41.00 -1.00 % en 50.00m PCV=1+110.00 Elev=40.50 PIV=1+130.00 Elev=40.30 PTV=1+150.00 Elev=40.52 +1.10 % en 70.00m PCV=1+220.00 Elev=41.29 PIV=1+240.00 Elev=41.51 PTV=1+260.00 Elev=41.49 -0.10 % en 80.00m PCV=1+340.00 Elev=41.41 PIV=1+360.00 Elev=41.39 PTV=1+380.00 Elev=41.71 +1.60 % en 80.00m PCV=1+460.00 Elev=42.99 PIV=1+480.00 Elev=43.31 PTV=1+500.00 Elev=44.19 +4.40 % en 40.00m PCV=1+540.00 Elev=45.95 PIV=1+560.00 Elev=46.83 PTV=1+580.00 Elev=47.01 +0.90 % en 40.00m PCV=1+620.00 Elev=47.37 PIV=1+640.00 Elev=47.55 PTV=1+660.00 Elev=47.25 PCV=1+660.00 Elev=47.25 PIV=1+680.00 Elev=46.95 PTV=1+700.00 Elev=47.13 +0.90 % en 90.00m PCV=1+790.00 Elev=47.94 PIV=1+810.00 Elev=48.12 PTV=1+830.00 Elev=47.78 -1.70 % en 50.00m PCV=1+880.00 Elev=46.93 PIV=1+900.00 Elev=46.59 PTV=1+920.00 Elev=46.67 +0.40 % en 20.05m -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 41 42 43 44 45 46 L C R=43.60 T.N.=43.85 OFF=-4.70 R=43.85 OFF=4.70 R=43.85 AREA DE CORTE = 3.58m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.88m2 SUBRASANTE = 2.69m2 BASE = 1.59m2 CARPETA = 0.36m2 -2.00% -2.00% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+000.00 0+000.00 10,000 0.00 0.00 0.25 43.60 43.85 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 40 41 42 43 44 45 L C R=42.68 T.N.=42.64 OFF=-4.60 R=42.72 OFF=4.59 R=42.71 AREA DE CORTE = 0.95m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.84m2 SUBRASANTE = 2.69m2 BASE = 1.59m2 CARPETA = 0.36m2 -2.00% -2.00% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+020.00 0+020.00 9,991 0.41 45.24 0.04 42.68 42.64 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 39 40 41 42 43 44 45 L C R=41.98 T.N.=41.85 OFF=-4.57 R=41.97 OFF=4.30 R=41.89 AREA DE CORTE = 0.36m2 AREA DE TERRAPLEN = 0.19m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.78m2 SUBRASANTE = 2.63m2 BASE = 1.59m2 CARPETA = 0.36m2 -2.00% -2.00% 1.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+040.00 0+040.00 9,948 2.08 13.08 0.13 41.98 41.85 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 39 40 41 42 43 44 L C R=41.45 T.N.=41.31 OFF=-4.56 R=41.41 OFF=4.55 R=41.39 AREA DE CORTE = 0.52m2 AREA DE TERRAPLEN = 0.05m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.82m2 SUBRASANTE = 2.69m2 BASE = 1.59m2 CARPETA = 0.36m2 -2.00% -2.00% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+060.00 0+060.00 9,902 2.41 8.84 0.14 41.45 41.31 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 44 L C R=41.18 T.N.=41.01 OFF=-4.03 R=41.01 OFF=4.00 R=41.02 AREA DE CORTE = 0.01m2 AREA DE TERRAPLEN = 0.44m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.61m2 SUBRASANTE = 2.40m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+080.00 0+080.00 9,849 4.90 5.28 0.17 41.18 41.01 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 44 L C R=41.04 T.N.=40.82 OFF=-4.10 R=40.82 OFF=4.20 R=40.75 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 0.90m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.66m2 SUBRASANTE = 2.44m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+100.00 0+100.00 9,787 13.32 0.06 0.22 41.04 40.82 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 L C R=40.90 T.N.=40.74 OFF=-4.22 R=40.62 OFF=4.16 R=40.64 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 0.64m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.68m2 SUBRASANTE = 2.45m2 BASE = 1.49m2 CARPETA = 0.35m2 -1.35% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+120.00 0+120.00 9,723 15.40 0.00 0.16 40.90 40.74 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 L C R=40.85 T.N.=40.78 OFF=-4.30 R=40.62 OFF=4.68 R=40.78 AREA DE CORTE = 0.33m2 AREA DE TERRAPLEN = 0.31m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.80m2 SUBRASANTE = 2.61m2 BASE = 1.57m2 CARPETA = 0.36m2 +0.89% -2.00% 0.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+140.00 0+140.00 9,668 9.54 3.33 0.07 40.85 40.78 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 44 L C R=41.00 T.N.=40.85 OFF=-4.33 R=40.80 OFF=4.34 R=40.85 AREA DE CORTE = 0.07m2 AREA DE TERRAPLEN = 0.52m2 AREA DESPALME TERRAPLEN = 0.02m2 AREA DESPALME CORTE = 1.72m2 SUBRASANTE = 2.53m2 BASE = 1.57m2 CARPETA = 0.37m2 +2.50% -2.50% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+160.00 0+160.00 9,611 8.31 4.03 0.15 41.00 40.85 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 44 L C R=41.24 T.N.=41.03 OFF=-4.39 R=40.97 OFF=4.29 R=41.07 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 0.96m2 AREA DESPALME TERRAPLEN = 0.14m2 AREA DESPALME CORTE = 1.59m2 SUBRASANTE = 2.51m2 BASE = 1.55m2 CARPETA = 0.37m2 +1.66% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+180.00 0+180.00 9,546 14.78 0.71 0.21 41.24 41.03 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 39 40 41 42 43 44 L C R=41.48 T.N.=41.28 OFF=-4.14 R=41.29 OFF=4.07 R=41.28 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 0.61m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.64m2 SUBRASANTE = 2.43m2 BASE = 1.49m2 CARPETA = 0.35m2 -0.57% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+200.00 0+200.00 9,481 15.63 0.01 0.20 41.48 41.28 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 39 40 41 42 43 44 L C R=41.90 T.N.=41.72 OFF=-4.18 R=41.63 OFF=4.12 R=41.67 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 0.55m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.66m2 SUBRASANTE = 2.45m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+220.00 0+220.00 9,420 11.53 0.00 0.18 41.90 41.72 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 40 41 42 43 44 45 L C R=42.68 T.N.=42.34 OFF=-4.28 R=42.34 OFF=4.01 R=42.52 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 1.34m2 AREA DESPALME TERRAPLEN = 0.54m2 AREA DESPALME CORTE = 1.12m2 SUBRASANTE = 2.43m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+240.00 0+240.00 9,353 18.86 0.02 0.34 42.68 42.34 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 41 42 43 44 45 46 L C R=43.64 T.N.=43.55 OFF=-4.17 R=43.52 OFF=4.88 R=43.75 AREA DE CORTE = 0.41m2 AREA DE TERRAPLEN = 0.33m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.81m2 SUBRASANTE = 2.64m2 BASE = 1.59m2 CARPETA = 0.37m2 +1.65% -2.00% 0.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+260.00 0+260.00 9,291 16.72 4.17 0.09 43.64 43.55 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 42 43 44 45 46 47 L C R=44.60 T.N.=44.64 OFF=-4.02 R=44.59 OFF=4.95 R=44.75 AREA DE CORTE = 1.17m2 AREA DE TERRAPLEN = 0.03m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.80m2 SUBRASANTE = 2.63m2 BASE = 1.60m2 CARPETA = 0.37m2 +2.00% -2.00% 0.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+280.00 0+280.00 9,251 3.59 15.81 0.04 44.60 44.64 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 43 44 45 46 47 48 49 L C R=45.56 T.N.=45.84 OFF=-4.62 R=45.82 OFF=5.03 R=45.92 AREA DE CORTE = 3.16m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.93m2 SUBRASANTE = 2.79m2 BASE = 1.65m2 CARPETA = 0.37m2 +1.85% -2.00% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+300.00 0+300.00 9,241 0.47 43.28 0.28 45.56 45.84 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 44 45 46 47 48 49 50 L C R=46.30 T.N.=47.08 OFF=-5.00 R=47.15 OFF=4.99 R=47.16 AREA DE CORTE = 8.57m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 2.00m2 SUBRASANTE = 2.69m2 BASE = 1.59m2 CARPETA = 0.36m2 -2.00% -1.58% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+320.00 0+320.00 9,302 0.42 117.35 0.78 46.30 47.08 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 44 45 46 47 48 49 50 L C R=46.62 T.N.=47.70 OFF=-5.91 R=47.95 OFF=5.00 R=47.75 AREA DE CORTE = 12.09m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 2.19m2 SUBRASANTE = 2.90m2 BASE = 1.71m2 CARPETA = 0.39m2 -4.50% +4.50% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+340.00 0+340.00 9,455 0.41 206.63 1.08 46.62 47.70 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 44 45 46 47 48 49 50 L C R=46.72 T.N.=47.59 OFF=-5.78 R=47.79 OFF=4.94 R=47.73 AREA DE CORTE = 10.54m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 2.15m2 SUBRASANTE = 2.90m2 BASE = 1.71m2 CARPETA = 0.39m2 -4.50% +4.50% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+360.00 0+360.00 9,622 0.40 226.29 0.87 46.72 47.59 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 44 45 46 47 48 49 50 L C R=46.62 T.N.=46.84 OFF=-4.75 R=46.96 OFF=4.73 R=46.92 AREA DE CORTE = 3.43m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.90m2 SUBRASANTE = 2.69m2 BASE = 1.59m2 CARPETA = 0.36m2 -2.00% -2.00% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+380.00 0+380.00 9,704 0.41 139.66 0.22 46.62 46.84 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 43 44 45 46 47 48 49 L C R=46.12 T.N.=46.27 OFF=-4.64 R=46.25 OFF=4.69 R=46.35 AREA DE CORTE = 2.45m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.87m2 SUBRASANTE = 2.69m2 BASE = 1.59m2 CARPETA = 0.36m2 -2.00% -2.00% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+400.00 0+400.00 9,708 0.42 58.79 0.15 46.12 46.27 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 43 44 45 46 47 48 L C R=45.42 T.N.=45.69 OFF=-4.69 R=45.66 OFF=4.68 R=45.63 AREA DE CORTE = 3.26m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.88m2 SUBRASANTE = 2.69m2 BASE = 1.59m2 CARPETA = 0.36m2 -2.00% -2.00% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+420.00 0+420.00 9,711 0.42 57.08 0.27 45.42 45.69 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 42 43 44 45 46 47 48 L C R=44.72 T.N.=45.02 OFF=-4.74 R=45.06 OFF=4.69 R=44.94 AREA DE CORTE = 3.79m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.89m2 SUBRASANTE = 2.69m2 BASE = 1.59m2 CARPETA = 0.36m2 -2.00% -2.00% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+440.00 0+440.00 9,727 0.41 70.49 0.30 44.72 45.02 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 41 42 43 44 45 46 47 L C R=43.91 T.N.=44.03 OFF=-4.70 R=44.15 OFF=4.61 R=43.98 AREA DE CORTE = 2.43m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.86m2 SUBRASANTE = 2.69m2 BASE = 1.59m2 CARPETA = 0.36m2 -2.00% -2.00% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+460.00 0+460.00 9,736 0.41 62.25 0.12 43.91 44.03 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 40 41 42 43 44 45 46 L C R=42.86 T.N.=42.75 OFF=-4.06 R=42.67 OFF=3.94 R=42.74 AREA DE CORTE = 0.12m2 AREA DE TERRAPLEN = 0.04m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.60m2 SUBRASANTE = 2.39m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+480.00 0+480.00 9,707 0.64 25.50 0.11 42.86 42.75 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 39 40 41 42 43 44 L C R=41.70 T.N.=41.58 OFF=-4.10 R=41.48 OFF=4.08 R=41.49 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 0.26m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.64m2 SUBRASANTE = 2.43m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+500.00 0+500.00 9,657 3.01 1.18 0.12 41.70 41.58 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 L C R=40.65 T.N.=40.56 OFF=-4.05 R=40.46 OFF=4.02 R=40.48 AREA DE CORTE = 0.02m2 AREA DE TERRAPLEN = 0.04m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.62m2 SUBRASANTE = 2.41m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+520.00 0+520.00 9,606 2.95 0.17 0.09 40.65 40.56 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 37 38 39 40 41 42 L C R=39.82 T.N.=39.78 OFF=-3.97 R=39.69 OFF=4.57 R=39.82 AREA DE CORTE = 0.71m2 AREA DE TERRAPLEN = 0.01m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.71m2 SUBRASANTE = 2.53m2 BASE = 1.54m2 CARPETA = 0.36m2 -2.00% -2.00% 0.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+540.00 0+540.00 9,564 0.47 7.23 0.04 39.82 39.78 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 36 37 38 39 40 41 42 L C R=39.10 T.N.=39.14 OFF=-4.55 R=39.05 OFF=4.62 R=39.18 AREA DE CORTE = 1.48m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.83m2 SUBRASANTE = 2.69m2 BASE = 1.59m2 CARPETA = 0.36m2 -2.00% -2.00% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+560.00 0+560.00 9,535 0.27 21.83 0.04 39.10 39.14 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 36 37 38 39 40 41 L C R=38.56 T.N.=38.40 OFF=-4.02 R=38.40 OFF=4.20 R=38.28 AREA DE CORTE = 0.01m2 AREA DE TERRAPLEN = 0.45m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.64m2 SUBRASANTE = 2.43m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+580.00 0+580.00 9,491 4.71 14.82 0.16 38.56 38.40 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 35 36 37 38 39 40 41 L C R=38.40 T.N.=37.50 OFF=-4.94 R=37.62 OFF=4.89 R=37.66 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 6.52m2 AREA DESPALME TERRAPLEN = 1.97m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+600.00 0+600.00 9,373 69.73 0.06 0.90 38.40 37.50 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 35 36 37 38 39 40 41 L C R=38.42 T.N.=37.27 OFF=-5.70 R=37.25 OFF=5.83 R=37.18 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 10.93m2 AREA DESPALME TERRAPLEN = 2.31m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.52m2 BASE = 1.53m2 CARPETA = 0.36m2 -2.00% +1.36% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+620.00 0+620.00 9,149 174.49 0.00 1.15 38.42 37.27 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 34 35 36 37 38 39 40 41 L C R=38.44 T.N.=37.02 OFF=-6.48 R=36.94 OFF=6.40 R=36.96 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 14.96m2 AREA DESPALME TERRAPLEN = 2.58m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.68m2 BASE = 1.63m2 CARPETA = 0.39m2 -5.10% +5.10% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+640.00 0+640.00 8,840 258.86 0.00 1.42 38.44 37.02 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 34 35 36 37 38 39 40 41 L C R=38.46 T.N.=36.93 OFF=-6.56 R=36.86 OFF=6.52 R=36.85 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 16.32m2 AREA DESPALME TERRAPLEN = 2.62m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.63m2 BASE = 1.60m2 CARPETA = 0.38m2 -3.85% +3.85% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+660.00 0+660.00 8,474 312.74 0.00 1.53 38.46 36.93 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 34 35 36 37 38 39 40 41 L C R=38.48 T.N.=37.75 OFF=-7.12 R=36.25 OFF=7.19 R=36.25 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 11.30m2 AREA DESPALME TERRAPLEN = 2.95m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -0.70% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+680.00 0+680.00 8,145 276.19 0.00 0.73 38.48 37.75 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 34 35 36 37 38 39 40 41 L C R=38.50 T.N.=38.21 OFF=-6.77 R=36.50 OFF=6.67 R=36.57 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 4.90m2 AREA DESPALME TERRAPLEN = 1.55m2 AREA DESPALME CORTE = 1.31m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+700.00 0+700.00 7,933 162.00 0.00 0.29 38.50 38.21 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 33 34 35 36 37 38 39 40 41 L C R=38.52 T.N.=38.41 OFF=-7.75 R=35.87 OFF=7.69 R=35.91 AREA DE CORTE = 0.24m2 AREA DE TERRAPLEN = 6.09m2 AREA DESPALME TERRAPLEN = 1.97m2 AREA DESPALME CORTE = 1.30m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+720.00 0+720.00 7,777 109.88 2.43 0.11 38.52 38.41 0+740.00 6,988 756.75 17.42 0.18 38.42 38.60 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 33 34 35 36 37 38 39 40 41 L C R=38.06 T.N.=37.61 OFF=-7.25 R=36.10 OFF=7.03 R=36.28 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 7.02m2 AREA DESPALME TERRAPLEN = 2.59m2 AREA DESPALME CORTE = 0.38m2 SUBRASANTE = 2.77m2 BASE = 1.69m2 CARPETA = 0.40m2 +7.18% -7.18% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+760.00 0+760.00 6,187 766.11 14.99 0.45 38.06 37.61 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 34 35 36 37 38 39 40 L C R=37.72 T.N.=37.09 OFF=-6.42 R=36.29 OFF=6.01 R=36.60 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 7.35m2 AREA DESPALME TERRAPLEN = 2.51m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.75m2 BASE = 1.68m2 CARPETA = 0.40m2 +6.71% -6.71% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+780.00 0+780.00 5,987 143.76 0.00 0.63 37.72 37.09 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 34 35 36 37 38 39 40 L C R=37.64 T.N.=36.99 OFF=-4.89 R=36.99 OFF=4.99 R=36.87 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 5.13m2 AREA DESPALME TERRAPLEN = 1.98m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.49m2 BASE = 1.51m2 CARPETA = 0.36m2 +0.50% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+800.00 0+800.00 5,808 124.84 0.00 0.65 37.64 36.99 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 35 36 37 38 39 40 L C R=37.70 T.N.=37.20 OFF=-4.57 R=37.20 OFF=4.43 R=37.26 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 3.23m2 AREA DESPALME TERRAPLEN = 1.80m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -1.19% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+820.00 0+820.00 5,674 83.65 0.00 0.50 37.70 37.20 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 35 36 37 38 39 40 41 L C R=37.92 T.N.=37.50 OFF=-4.93 R=37.42 OFF=4.76 R=37.54 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 3.22m2 AREA DESPALME TERRAPLEN = 1.44m2 AREA DESPALME CORTE = 0.50m2 SUBRASANTE = 2.64m2 BASE = 1.63m2 CARPETA = 0.39m2 +5.03% -5.03% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+840.00 0+840.00 5,560 64.49 0.00 0.42 37.92 37.50 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 35 36 37 38 39 40 41 L C R=38.44 T.N.=37.98 OFF=-4.77 R=38.15 OFF=5.17 R=37.88 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 3.80m2 AREA DESPALME TERRAPLEN = 1.84m2 AREA DESPALME CORTE = 0.15m2 SUBRASANTE = 2.75m2 BASE = 1.69m2 CARPETA = 0.40m2 +7.60% -7.60% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+860.00 0+860.00 5,437 70.18 0.00 0.46 38.44 37.98 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 36 37 38 39 40 41 42 L C R=39.12 T.N.=38.67 OFF=-4.77 R=38.64 OFF=4.88 R=38.59 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 4.09m2 AREA DESPALME TERRAPLEN = 1.95m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.58m2 BASE = 1.57m2 CARPETA = 0.37m2 +2.78% -2.78% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+880.00 0+880.00 5,303 78.91 0.00 0.45 39.12 38.67 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 37 38 39 40 41 42 43 44 L C R=39.80 T.N.=39.74 OFF=-4.63 R=39.96 OFF=4.73 R=40.11 AREA DE CORTE = 0.66m2 AREA DE TERRAPLEN = 0.04m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.90m2 SUBRASANTE = 2.69m2 BASE = 1.59m2 CARPETA = 0.36m2 -1.08% -2.00% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+900.00 0+900.00 5,217 41.29 6.63 0.06 39.80 39.74 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 44 L C R=40.34 T.N.=40.65 OFF=-4.61 R=40.64 OFF=5.53 R=41.19 AREA DE CORTE = 4.15m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 2.04m2 SUBRASANTE = 2.86m2 BASE = 1.69m2 CARPETA = 0.38m2 +3.66% -3.66% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+920.00 0+920.00 5,211 0.62 48.18 0.31 40.34 40.65 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 L C R=40.60 T.N.=40.82 OFF=-4.53 R=40.79 OFF=5.36 R=40.83 AREA DE CORTE = 3.24m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.98m2 SUBRASANTE = 2.90m2 BASE = 1.71m2 CARPETA = 0.39m2 +4.50% -4.50% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+940.00 0+940.00 5,227 0.39 73.99 0.22 40.60 40.82 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 44 45 L C R=40.72 T.N.=41.73 OFF=-5.14 R=41.97 OFF=5.25 R=41.81 AREA DE CORTE = 11.79m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 2.08m2 SUBRASANTE = 2.73m2 BASE = 1.62m2 CARPETA = 0.37m2 +0.97% -2.00% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+960.00 0+960.00 5,319 0.36 150.34 1.01 40.72 41.73 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 44 L C R=40.84 T.N.=40.86 OFF=-4.54 R=40.77 OFF=4.62 R=40.92 AREA DE CORTE = 1.46m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.83m2 SUBRASANTE = 2.69m2 BASE = 1.59m2 CARPETA = 0.36m2 -2.00% -2.00% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 0+980.00 0+980.00 5,396 0.37 132.50 0.02 40.84 40.86 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 44 L C R=40.96 T.N.=41.00 OFF=-4.75 R=40.98 OFF=4.56 R=41.07 AREA DE CORTE = 1.49m2 AREA DE TERRAPLEN = 0.58m2 AREA DESPALME TERRAPLEN = 0.25m2 AREA DESPALME CORTE = 1.87m2 SUBRASANTE = 2.74m2 BASE = 1.62m2 CARPETA = 0.37m2 -2.00% +1.25% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+000.00 1+000.00 5,366 5.95 29.50 0.04 40.96 41.00 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 44 L C R=41.08 T.N.=41.37 OFF=-5.93 R=41.51 OFF=4.56 R=41.46 AREA DE CORTE = 4.82m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 2.10m2 SUBRASANTE = 3.03m2 BASE = 1.79m2 CARPETA = 0.41m2 -7.47% +7.47% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+020.00 1+020.00 5,368 5.97 63.05 0.29 41.08 41.37 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 44 45 L C R=41.12 T.N.=40.90 OFF=-4.92 R=40.71 OFF=4.70 R=40.86 AREA DE CORTE = 0.06m2 AREA DE TERRAPLEN = 1.48m2 AREA DESPALME TERRAPLEN = 0.72m2 AREA DESPALME CORTE = 1.21m2 SUBRASANTE = 2.70m2 BASE = 1.68m2 CARPETA = 0.40m2 -7.20% +7.20% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+040.00 1+040.00 5,342 14.98 48.71 0.22 41.12 40.90 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 44 L C R=41.00 T.N.=40.55 OFF=-4.37 R=40.68 OFF=4.62 R=40.55 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 2.97m2 AREA DESPALME TERRAPLEN = 1.71m2 AREA DESPALME CORTE = 0.09m2 SUBRASANTE = 2.50m2 BASE = 1.52m2 CARPETA = 0.36m2 -2.00% +0.98% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+060.00 1+060.00 5,244 44.47 0.55 0.45 41.00 40.55 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 37 38 39 40 41 42 43 L C R=40.80 T.N.=40.30 OFF=-4.74 R=40.15 OFF=4.53 R=40.30 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 3.36m2 AREA DESPALME TERRAPLEN = 1.86m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -1.89% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+080.00 1+080.00 5,130 63.28 0.00 0.50 40.80 40.30 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 37 38 39 40 41 42 43 L C R=40.60 T.N.=40.19 OFF=-5.20 R=39.98 OFF=4.94 R=40.07 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 3.69m2 AREA DESPALME TERRAPLEN = 2.03m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.67m2 BASE = 1.63m2 CARPETA = 0.39m2 -4.36% +4.36% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+100.00 1+100.00 5,010 70.46 0.00 0.41 40.60 40.19 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 37 38 39 40 41 42 43 L C R=40.43 T.N.=40.20 OFF=-6.17 R=40.15 OFF=5.34 R=39.83 AREA DE CORTE = 1.07m2 AREA DE TERRAPLEN = 2.98m2 AREA DESPALME TERRAPLEN = 0.92m2 AREA DESPALME CORTE = 1.39m2 SUBRASANTE = 3.02m2 BASE = 1.84m2 CARPETA = 0.43m2 -9.60% +9.60% 1.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+120.00 1+120.00 4,901 66.61 10.65 0.23 40.43 40.20 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 37 38 39 40 41 42 43 L C R=40.44 T.N.=40.17 OFF=-5.78 R=39.99 OFF=5.11 R=39.93 AREA DE CORTE = 0.13m2 AREA DE TERRAPLEN = 2.81m2 AREA DESPALME TERRAPLEN = 0.99m2 AREA DESPALME CORTE = 1.19m2 SUBRASANTE = 2.95m2 BASE = 1.79m2 CARPETA = 0.42m2 -7.96% +7.96% 1.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+140.00 1+140.00 4,795 57.83 11.98 0.27 40.44 40.17 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 L C R=40.63 T.N.=40.34 OFF=-4.47 R=40.34 OFF=4.35 R=40.39 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 1.64m2 AREA DESPALME TERRAPLEN = 0.54m2 AREA DESPALME CORTE = 1.23m2 SUBRASANTE = 2.54m2 BASE = 1.55m2 CARPETA = 0.37m2 -2.00% +1.70% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+160.00 1+160.00 4,693 44.47 1.33 0.29 40.63 40.34 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 L C R=40.85 T.N.=40.35 OFF=-4.53 R=40.34 OFF=4.41 R=40.43 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 3.23m2 AREA DESPALME TERRAPLEN = 1.79m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+180.00 1+180.00 4,593 48.72 0.00 0.50 40.85 40.35 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 44 L C R=41.07 T.N.=40.62 OFF=-4.73 R=40.43 OFF=4.45 R=40.62 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 3.13m2 AREA DESPALME TERRAPLEN = 1.84m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+200.00 1+200.00 4,480 63.68 0.00 0.45 41.07 40.62 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 44 L C R=41.29 T.N.=40.70 OFF=-4.96 R=40.50 OFF=4.80 R=40.60 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 4.33m2 AREA DESPALME TERRAPLEN = 1.96m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+220.00 1+220.00 4,356 74.60 0.00 0.59 41.29 40.70 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 44 L C R=41.45 T.N.=40.73 OFF=-5.16 R=40.52 OFF=5.60 R=40.23 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 6.41m2 AREA DESPALME TERRAPLEN = 2.16m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+240.00 1+240.00 4,199 107.34 0.00 0.72 41.45 40.73 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 44 L C R=41.49 T.N.=40.88 OFF=-4.83 R=40.78 OFF=5.04 R=40.65 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 4.99m2 AREA DESPALME TERRAPLEN = 1.98m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+260.00 1+260.00 4,036 113.97 0.00 0.61 41.49 40.88 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 44 L C R=41.47 T.N.=40.98 OFF=-4.78 R=40.98 OFF=4.70 R=41.03 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 3.56m2 AREA DESPALME TERRAPLEN = 1.90m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.57m2 BASE = 1.56m2 CARPETA = 0.37m2 +2.65% -2.65% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+280.00 1+280.00 3,901 85.49 0.00 0.49 41.47 40.98 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 44 45 L C R=41.45 T.N.=40.89 OFF=-4.85 R=41.03 OFF=5.67 R=42.04 AREA DE CORTE = 3.08m2 AREA DE TERRAPLEN = 2.97m2 AREA DESPALME TERRAPLEN = 1.20m2 AREA DESPALME CORTE = 1.05m2 SUBRASANTE = 2.78m2 BASE = 1.68m2 CARPETA = 0.39m2 +5.60% -5.60% 0.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+300.00 1+300.00 3,815 65.35 30.78 0.56 41.45 40.89 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 38 39 40 41 42 43 44 L C R=41.43 T.N.=41.13 OFF=-4.36 R=41.25 OFF=5.00 R=41.28 AREA DE CORTE = 0.13m2 AREA DE TERRAPLEN = 1.53m2 AREA DESPALME TERRAPLEN = 1.38m2 AREA DESPALME CORTE = 0.50m2 SUBRASANTE = 2.71m2 BASE = 1.63m2 CARPETA = 0.38m2 +3.62% -3.62% 0.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+320.00 1+320.00 3,746 45.02 32.12 0.30 41.43 41.13 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 39 40 41 42 43 44 L C R=41.41 T.N.=41.32 OFF=-3.94 R=41.32 OFF=3.91 R=41.32 AREA DE CORTE = 0.34m2 AREA DE TERRAPLEN = 0.00m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.57m2 SUBRASANTE = 2.35m2 BASE = 1.49m2 CARPETA = 0.35m2 -1.38% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+340.00 1+340.00 3,682 15.27 4.72 0.09 41.41 41.32 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 39 40 41 42 43 44 L C R=41.48 T.N.=41.42 OFF=-4.57 R=41.45 OFF=4.55 R=41.42 AREA DE CORTE = 0.94m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.82m2 SUBRASANTE = 2.69m2 BASE = 1.59m2 CARPETA = 0.36m2 -2.00% -2.00% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+360.00 1+360.00 3,647 0.16 12.77 0.06 41.48 41.42 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 39 40 41 42 43 44 L C R=41.71 T.N.=41.59 OFF=-3.92 R=41.61 OFF=3.95 R=41.59 AREA DE CORTE = 0.31m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.58m2 SUBRASANTE = 2.36m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+380.00 1+380.00 3,605 0.36 12.47 0.12 41.71 41.59 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 39 40 41 42 43 44 45 L C R=42.03 T.N.=41.76 OFF=-4.20 R=41.89 OFF=4.39 R=41.76 AREA DE CORTE = 0.13m2 AREA DE TERRAPLEN = 1.17m2 AREA DESPALME TERRAPLEN = 0.53m2 AREA DESPALME CORTE = 1.19m2 SUBRASANTE = 2.49m2 BASE = 1.54m2 CARPETA = 0.37m2 -2.00% +1.75% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+400.00 1+400.00 3,551 11.93 4.43 0.27 42.03 41.76 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 40 41 42 43 44 45 L C R=42.35 T.N.=42.14 OFF=-5.24 R=42.34 OFF=4.46 R=42.14 AREA DE CORTE = 0.65m2 AREA DE TERRAPLEN = 1.07m2 AREA DESPALME TERRAPLEN = 0.49m2 AREA DESPALME CORTE = 1.46m2 SUBRASANTE = 2.75m2 BASE = 1.66m2 CARPETA = 0.39m2 -4.50% +4.50% 1.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+420.00 1+420.00 3,486 22.47 7.85 0.21 42.35 42.14 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 40 41 42 43 44 45 L C R=42.67 T.N.=42.35 OFF=-4.96 R=42.55 OFF=4.54 R=42.35 AREA DE CORTE = 0.20m2 AREA DE TERRAPLEN = 1.79m2 AREA DESPALME TERRAPLEN = 1.04m2 AREA DESPALME CORTE = 0.87m2 SUBRASANTE = 2.70m2 BASE = 1.62m2 CARPETA = 0.38m2 -3.08% +3.08% 1.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+440.00 1+440.00 3,411 28.62 8.50 0.32 42.67 42.35 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 40 41 42 43 44 45 L C R=42.99 T.N.=42.69 OFF=-3.92 R=42.89 OFF=4.28 R=42.69 AREA DE CORTE = 0.07m2 AREA DE TERRAPLEN = 1.24m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.65m2 SUBRASANTE = 2.41m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -0.93% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+460.00 1+460.00 3,329 30.28 2.65 0.30 42.99 42.69 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 41 42 43 44 45 46 L C R=43.45 T.N.=43.11 OFF=-4.56 R=43.42 OFF=4.18 R=43.18 AREA DE CORTE = 0.16m2 AREA DE TERRAPLEN = 1.48m2 AREA DESPALME TERRAPLEN = 0.80m2 AREA DESPALME CORTE = 0.97m2 SUBRASANTE = 2.57m2 BASE = 1.54m2 CARPETA = 0.36m2 -2.00% -2.00% 1.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+480.00 1+480.00 3,256 27.23 2.23 0.34 43.45 43.11 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 41 42 43 44 45 46 47 L C R=44.19 T.N.=43.71 OFF=-4.03 R=44.02 OFF=4.72 R=44.49 AREA DE CORTE = 0.28m2 AREA DE TERRAPLEN = 2.53m2 AREA DESPALME TERRAPLEN = 1.41m2 AREA DESPALME CORTE = 0.44m2 SUBRASANTE = 2.55m2 BASE = 1.54m2 CARPETA = 0.36m2 -2.00% -2.00% 0.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+500.00 1+500.00 3,169 40.15 4.34 0.48 44.19 43.71 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 42 43 44 45 46 47 48 L C R=45.07 T.N.=44.57 OFF=-4.47 R=44.61 OFF=4.57 R=44.53 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 3.42m2 AREA DESPALME TERRAPLEN = 1.82m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+520.00 1+520.00 3,061 59.56 2.77 0.50 45.07 44.57 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 43 44 45 46 47 48 49 L C R=45.95 T.N.=45.55 OFF=-4.39 R=45.60 OFF=4.92 R=45.18 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 2.54m2 AREA DESPALME TERRAPLEN = 1.87m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -0.47% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+540.00 1+540.00 2,952 59.69 0.00 0.40 45.95 45.55 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 44 45 46 47 48 49 50 51 L C R=46.65 T.N.=46.55 OFF=-4.14 R=46.60 OFF=4.94 R=46.55 AREA DE CORTE = 0.34m2 AREA DE TERRAPLEN = 0.20m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.82m2 SUBRASANTE = 2.68m2 BASE = 1.62m2 CARPETA = 0.38m2 +3.01% -3.01% 0.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+560.00 1+560.00 2,879 27.49 3.37 0.10 46.65 46.55 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 44 45 46 47 48 49 50 51 52 L C R=47.01 T.N.=47.42 OFF=-4.65 R=47.42 OFF=5.33 R=47.42 AREA DE CORTE = 5.02m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 2.00m2 SUBRASANTE = 2.87m2 BASE = 1.69m2 CARPETA = 0.38m2 +3.90% -3.90% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+580.00 1+580.00 2,876 2.24 53.60 0.41 47.01 47.42 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 45 46 47 48 49 50 51 L C R=47.19 T.N.=47.97 OFF=-4.99 R=48.17 OFF=5.15 R=47.98 AREA DE CORTE = 8.90m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 2.03m2 SUBRASANTE = 2.75m2 BASE = 1.63m2 CARPETA = 0.37m2 +1.35% -2.00% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+600.00 1+600.00 2,958 0.40 139.24 0.78 47.19 47.97 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 45 46 47 48 49 50 51 L C R=47.37 T.N.=47.80 OFF=-4.84 R=47.89 OFF=4.74 R=47.70 AREA DE CORTE = 5.32m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.92m2 SUBRASANTE = 2.69m2 BASE = 1.59m2 CARPETA = 0.36m2 -2.00% -2.00% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+620.00 1+620.00 3,045 0.40 142.17 0.43 47.37 47.80 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 45 46 47 48 49 50 L C R=47.43 T.N.=47.24 OFF=-4.00 R=47.27 OFF=4.29 R=47.08 AREA DE CORTE = 0.01m2 AREA DE TERRAPLEN = 0.46m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.66m2 SUBRASANTE = 2.43m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+640.00 1+640.00 3,039 4.76 53.22 0.19 47.43 47.24 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 44 45 46 47 48 49 50 L C R=47.25 T.N.=46.64 OFF=-4.63 R=46.67 OFF=4.78 R=46.58 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 4.45m2 AREA DESPALME TERRAPLEN = 1.89m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+660.00 1+660.00 2,942 49.08 0.05 0.61 47.25 46.64 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 44 45 46 47 48 49 50 L C R=47.07 T.N.=46.21 OFF=-5.14 R=46.16 OFF=4.99 R=46.26 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 6.81m2 AREA DESPALME TERRAPLEN = 2.02m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+680.00 1+680.00 2,780 112.63 0.00 0.86 47.07 46.21 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 43 44 45 46 47 48 49 50 L C R=47.13 T.N.=46.21 OFF=-6.65 R=45.21 OFF=5.60 R=45.91 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 9.75m2 AREA DESPALME TERRAPLEN = 2.50m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+700.00 1+700.00 2,565 165.64 0.00 0.92 47.13 46.21 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 44 45 46 47 48 49 50 L C R=47.31 T.N.=46.70 OFF=-4.88 R=46.57 OFF=4.39 R=46.90 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 4.62m2 AREA DESPALME TERRAPLEN = 1.87m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+720.00 1+720.00 2,371 143.67 0.00 0.61 47.31 46.70 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 45 46 47 48 49 50 L C R=47.49 T.N.=47.15 OFF=-4.09 R=47.27 OFF=4.28 R=47.15 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 1.62m2 AREA DESPALME TERRAPLEN = 0.80m2 AREA DESPALME CORTE = 0.88m2 SUBRASANTE = 2.45m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+740.00 1+740.00 2,260 62.33 0.00 0.34 47.49 47.15 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 45 46 47 48 49 50 L C R=47.67 T.N.=47.27 OFF=-4.25 R=47.35 OFF=4.37 R=47.27 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 2.14m2 AREA DESPALME TERRAPLEN = 1.52m2 AREA DESPALME CORTE = 0.20m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+760.00 1+760.00 2,173 37.61 0.00 0.40 47.67 47.27 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 45 46 47 48 49 50 L C R=47.85 T.N.=47.02 OFF=-4.95 R=47.06 OFF=4.72 R=47.22 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 6.27m2 AREA DESPALME TERRAPLEN = 1.94m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+780.00 1+780.00 2,040 84.12 0.00 0.83 47.85 47.02 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 44 45 46 47 48 49 50 L C R=48.00 T.N.=46.78 OFF=-4.97 R=47.20 OFF=5.74 R=46.69 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 10.48m2 AREA DESPALME TERRAPLEN = 2.15m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+800.00 1+800.00 1,823 167.53 0.00 1.22 48.00 46.78 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 44 45 46 47 48 49 50 L C R=47.92 T.N.=46.66 OFF=-5.87 R=46.52 OFF=5.78 R=46.58 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 11.93m2 AREA DESPALME TERRAPLEN = 2.33m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+820.00 1+820.00 1,549 224.13 0.00 1.26 47.92 46.66 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 44 45 46 47 48 49 50 L C R=47.61 T.N.=46.84 OFF=-5.02 R=46.78 OFF=5.03 R=46.77 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 6.05m2 AREA DESPALME TERRAPLEN = 2.01m2 AREA DESPALME CORTE = 0.00m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+840.00 1+840.00 1,320 179.75 0.00 0.77 47.61 46.84 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 44 45 46 47 48 49 50 L C R=47.27 T.N.=46.92 OFF=-4.42 R=46.84 OFF=4.38 R=46.86 AREA DE CORTE = 0.00m2 AREA DE TERRAPLEN = 1.88m2 AREA DESPALME TERRAPLEN = 1.33m2 AREA DESPALME CORTE = 0.43m2 SUBRASANTE = 2.47m2 BASE = 1.49m2 CARPETA = 0.35m2 -2.00% -2.00% 1.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+860.00 1+860.00 1,191 79.27 0.00 0.35 47.27 46.92 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 44 45 46 47 48 49 50 L C R=46.93 T.N.=46.92 OFF=-4.58 R=46.93 OFF=4.61 R=47.00 AREA DE CORTE = 1.31m2 AREA DE TERRAPLEN = 0.02m2 AREA DESPALME TERRAPLEN = 0.00m2 AREA DESPALME CORTE = 1.84m2 SUBRASANTE = 2.69m2 BASE = 1.59m2 CARPETA = 0.36m2 -2.00% -2.00% 0.5:1 0.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+880.00 1+880.00 1,136 18.99 13.11 0.01 46.93 46.92 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 44 45 46 47 48 49 50 L C R=46.69 T.N.=46.83 OFF=-4.42 R=46.66 OFF=5.89 R=46.76 AREA DE CORTE = 3.10m2 AREA DE TERRAPLEN = 0.25m2 AREA DESPALME TERRAPLEN = 0.13m2 AREA DESPALME CORTE = 1.93m2 SUBRASANTE = 2.90m2 BASE = 1.76m2 CARPETA = 0.41m2 +8.20% -8.20% 0.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+900.00 1+900.00 1,124 2.65 44.15 0.14 46.69 46.83 -13 -12 -11 -10 -9 -8 -7 -6 -5 -4 -3 -2 -1 0 1 2 3 4 5 6 7 8 9 10 11 12 13 44 45 46 47 48 49 L C R=46.67 T.N.=46.76 OFF=-4.33 R=46.69 OFF=5.83 R=46.61 AREA DE CORTE = 2.20m2 AREA DE TERRAPLEN = 0.20m2 AREA DESPALME TERRAPLEN = 0.04m2 AREA DESPALME CORTE = 1.99m2 SUBRASANTE = 2.90m2 BASE = 1.76m2 CARPETA = 0.41m2 +8.20% -8.20% 0.5:1 1.5:1 ESCALA HORIZONTAL 1 : 100 ESCALA VERTICAL 1 : 100 ESTACION 1+920.00 1+920.00 1,114 4.49 53.00 0.09 46.67 46.76 1+940.00 1,088 6.67 38.89 0.25 46.75 47.00 TOTAL VOLUMEN CORTE = 2,431.88m3 TOTAL VOLUMEN TERRAPLEN = -11,343.73m3 TOTAL VOLUMEN DESPALME EN CORTE = 3,253.39m3 TOTAL VOLUMEN DESPALME EN TERRAPLEN = -1,686.49m3 A 1.000 1.000 AZ=214°0'0.00" TAN=143.26m D = 6°4'0.00" der ST = 20.241 PI = 0+163.49 Gc = 3°0'0.00" Lc = 40.444 Rc = 381.972 Sc = 2.50% Ac = 0.40 Le entrada = 22.40 Le salida = 22.40 PC=0+143.25 PT=0+183.70 AZ=220°4'0.00" TAN=73.04m D = 4°46'0.00" der ST = 23.764 PI = 0+280.50 Gc = 2°0'0.00" Lc = 47.500 Rc = 572.958 Sc = 2.00% Ac = 0.30 Le entrada = 10.00 Le salida = 10.00 PC=0+256.73 PT=0+304.23 AZ=224°50'0.00" TAN=22.49m D = 12°14'0.00" izq ST = 20.467 PI = 0+347.19 Gc = 6°0'0.00" Lc = 40.778 Rc = 190.986 Sc = 4.50% Ac = 0.60 Le entrada = 7.90 Le salida = 7.90 PC=0+326.72 PT=0+367.50 AZ=212°36'0.00" TAN=257.74m D = 14°10'0.00" izq ST = 20.342 PI = 0+645.58 Gc = 7°0'0.00" Lc = 40.476 Rc = 163.702 Sc = 5.10% Ac = 0.70 Le entrada = 22.40 Le salida = 22.40 PC=0+625.24 PT=0+665.72 AZ=198°26'0.00" TAN=83.89m D = 27°30'0.00" der ST = 20.029 PI = 0+769.64 Gc = 14°0'0.00" Lc = 39.286 Rc = 81.851 Sc = 7.90% Ac = 1.10 Le entrada = 25.43 Le salida = 25.43 PC=0+749.61 PT=0+788.89 AZ=225°56'0.00" TAN=47.15m D = 26°26'0.00" der ST = 20.702 PI = 0+856.74 Gc = 13°0'0.00" Lc = 40.667 Rc = 88.147 Sc = 7.60% Ac = 1.00 Le entrada = 24.44 Le salida = 24.44 PC=0+836.04 PT=0+876.71 AZ=252°22'0.00" TAN=37.33m D = 12°10'0.00" der ST = 20.354 PI = 0+934.40 Gc = 6°0'0.00" Lc = 40.556 Rc = 190.986 Sc = 4.50% Ac = 0.60 Le entrada = 19.00 Le salida = 19.00 PC=0+914.04 PT=0+954.60 AZ=264°32'0.00" TAN=53.61m D = 27°46'0.00" izq ST = 21.787 PI = 1+029.99 Gc = 13°0'0.00" Lc = 42.718 Rc = 88.147 Sc = 7.60% Ac = 1.00 Le entrada = 24.44 Le salida = 24.44 PC=1+008.21 PT=1+050.92 AZ=236°46'0.00" TAN=50.47m D = 56°0'0.00" izq ST = 26.491 PI = 1+127.89 Gc = 23°0'0.00" Lc = 48.696 Rc = 49.822 Sc = 9.60% Ac = 1.50 Le entrada = 30.71 Le salida = 30.71 PC=1+101.40 PT=1+150.09 AZ=180°45'59.99" TAN=130.51m D = 17°4'0.00" der ST = 21.492 PI = 1+302.09 Gc = 8°0'0.00" Lc = 42.667 Rc = 143.239 Sc = 5.60% Ac = 0.70 Le entrada = 22.40 Le salida = 22.40 PC=1+280.60 PT=1+323.27 AZ=197°50'0.00" TAN=79.21m D = 12°30'0.00" izq ST = 20.916 PI = 1+423.39 Gc = 6°0'0.00" Lc = 41.667 Rc = 190.986 Sc = 4.50% Ac = 0.60 Le entrada = 22.40 Le salida = 22.40 PC=1+402.48 PT=1+444.14 AZ=185°20'0.00" TAN=109.75m D = 10°40'0.00" der ST = 21.395 PI = 1+575.29 Gc = 5°0'0.00" Lc = 42.667 Rc = 229.183 Sc = 3.90% Ac = 0.50 Le entrada = 22.40 Le salida = 22.40 PC=1+553.89 PT=1+596.56 AZ=196°0'0.00" TAN=299.15m D = 31°16'0.10" der ST = 21.378 PI = 1+917.08 Gc = 15°0'0.00" Lc = 41.689 Rc = 76.394 Sc = 8.20% Ac = 1.10 Le entrada = 3.00 Le salida = 3.00 PC=1+895.71 PT=1+937.39 VERTICAL: 1 : 200 HORIZONTAL: 1 : 2000 BORDO PARA CANALES COMP. A O B R A S D E D R E N A J E CARACTERISTICAS DEL TRAMO DEMOLICIONES ACERO ESTRUCTURAL ACERO DE REFUERZO E S P E C I F I C A C I O N E S D E L P R O Y E C T O CAMINO TIPO VELOCIDAD DE PROYECTO ANCHO DE CORONA ESPESOR DE CARPETA ESPESOR DE BASE CURVATURA MAXIMA PENDIENTE GOBERNADORA PENDIENTE MAXIMA P E R F I L D E C O N S T R U C C I O N E S C A L A S F'c = 150 KGS/CM2 F'c = 200 KGS/CM2 F'c = 100 KGS/CM2 DE 3A. MORT.CEMENTO C O N C E P T O S CONCRETO CICLOPEO MASA EXCAVACIONES MAMPOSTERIA ZAMPEADO MATERIAL C SECA MATERIAL B MATERIAL A M3. M3. M3. M3. M3. M U R O S M3. M3. M3. M3. T U B O S M3. M3. KM/H M M M ° % % UNIDAD M3 M3 M3 M3 M M M M M3 MAMPOSTERIA MAMPOSTERIA EN ESTE PLANO EXCAVACION CONCRETO DE 0.75 M DE 1.20 M DE 1.05 M DE 0.90 M TONS DE TERRACERIAS DE PAVIMENTOS NATURAL EN EL DE LOS CORTES DESPLANTES EN EN TERRAPLENES EN TERRAPLENES DEL TENDIDO DE DE ELEVACION DE EN TERRAPLENES DE LA AMPLIACION DEL RELLENO FORMAR MAT. NO COMP. CAPA SUBRASANTE CONSTRUIDA SOBRE DE AFINAMIENTO. CON O SIN CUÑA DE TERRAPLENES EXISTENTES TERRAPLENES AREA DE DE LA CAMA DEL TERRENO EN CORTES TALUDES EXISTENTES EXISTENTES DE LACORONA EXISTENTES SUBRASANTE TERRAPLENES SUPERIOR DE DE LA CAPA EXISTENTES MATERIAL PRODUCTO DE LOS PRESTAMOS T E R R A C E R I A S C A N T I D A D E S DE O B R A A C A R R E O S P A R A T E R R A C E R I A S M3 EST C O M P A C T A C I O N GEOMETRICO EN LA EXCAVACION EXCAVACIONES M3 HM-AD MATERIAL PRODUCTO DE LOS CORTES LATERALES GEOMETRICO EN EL PRESTAMO PRESTAMOS M3 EST M3 HM LA FAJA DE DE BANCO DENTRO DE DESPALME TOTAL M3. ABAJO SUBRASANTE CORTES A,B,C ESCALONES M. F O R M A C I O N Y M3. 40.00 M3 HM-KM M3 KM 100.00 80.00 60.00 M. M. M. M3. M3. M3. M3. MATERIAL B MATERIAL C MATERIAL A 20.00 M. MAT. APROVECHADO MAT. DESPERDICIADO MAT. DESPERDICIADO MAT. APROVECHADO M3. M3. M3. M3. M3. M3. M3. M3. M3. AMPLIACION DE CORTES REBAJES DE CORONA DE CORTE Y/O TERRAPLEN. M3. CORTE ADICIONAL TOTAL DESPERDICIO = DESPALME C O M P A C T A C I O N E S M3. TERRAPLEN MAT. APROVECHADO MAT. DESPERDICIADO MAT. APROVECHADO MAT. DESPERDICIADO MAT. APROVECHADO MAT. DESPERDICIADO MATERIAL C MATERIAL A MATERIAL B M3. M3. M3. M3. M3. M3. M3. M3. M3. CORTE VOL.GEOM. M3. M3. M3. A 90 % M3 HM-KM M3. M3. M3. M3. M3. M3. M3. M3. M3. M3. M3. M3. M3. A 90 % M3 HM-HM A 100 % A 95 % A 90 % A 100 % A 95 % M3 HM M3 KM A 100 % A 100 % A 100 % A 90 % A 95 % A 100 % A 95 % A 95 % M3. M3. M3. M3. M3. M3. M3. M3. M3. M3. M3. M3. M3. M3. M3. M3. A 90 % A 90 % A 95 % A 100 % A 90 % A 100 % A 95 % A 95 % A 100 % A 90 % BANDEADO A 95 % A 90 % A 100 % A 95 % BANDEADO " D " 30 7.00 0.05 0.20 50 8.00 12.00 " D " 30 7.00 0.05 0.20 50 8.00 12.00 CHILPANCINGO GRO; ENERO DE 2009. DEPARTAMENTO DE ESTUDIOS Y PROYECTOS LEVANTAMIENTO: PROYECTÓ: GRAFICOS: DATOS DEL PROYECTO: TRAMO: 0+000 AL 3+020 CAMINO: LA CONCEPCION - QUIAHUITLATZALA REGION: 04 - MONTAÑA ESTRUCTURA DEL PAVIMENTO CORTE CARPETA 1/4:1 TERRACERIA EXISTENTE TERRENO NATURAL 3:1 LINEA SUBRASANTE DE PROYECTO TERRAPLEN 1.5:1 EJE DE PROYECTO L C SECCION TIPO 0.05 0.20 0.30 BASE SUBRASANTE META: 1.94 KM DE ESTACION: KM 0+000 AL 1+940 CAMINO: COPALA - ATRIXCO REGION: DATOS DEL PROYECTO: D 40 KM/HR. DEL TRAMO CONCEPTO: CAMINO TIPO: VELOCIDAD DE PROYECTO: 60° 20 CMS. 6 MTS. 12.00 % 8.00 % ESPESOR DE BASE: CURVATURA MAXIMA: PENDIENTE MAXIMA: ANCHO DE CALZADA: PENDIENTE GOBERNADORA: ANCHO DE CORONA: 7 MTS. CARACTERISTICAS PLANO: ARCHIVO: REVISO: LEVANTO: FECHA: TOP. BULMARO PRIETO AGOSTO /2010 NUM: 1:100 ACOTACIONES : ESCALA: GRAFICOS: PROYECTO: DEPARTAMENTO DE PROYECTOS: SECCIONES DEL KM 0+000 AL KM 0+360 EN METROS. P-1 G U E R R E R O \A1;CORONA = 7.00 m 3.50 3.50 \A1;1.00 0.00 0.00 ESTRUCTURA DEL PAVIMENTO CORTE CARPETA 1/4:1 TERRACERIA EXISTENTE TERRENO NATURAL 3:1 LINEA SUBRASANTE DE PROYECTO TERRAPLEN 1.5:1 EJE DE PROYECTO L C SECCION TIPO 0.05 0.20 0.30 BASE SUBRASANTE META: 3.02 KM DE ESTACION: KM 0+000 AL 3+020 CAMINO: LA CONCEPCION - QUIAHUITLATZALA REGION: 04 - MONTAÑA DATOS DEL PROYECTO: D 40 KM/HR. DEL TRAMO CONCEPTO: CAMINO TIPO: VELOCIDAD DE PROYECTO: 60° 20 CMS. 6 MTS. 12.00 % 8.00 % ESPESOR DE BASE: CURVATURA MAXIMA: PENDIENTE MAXIMA: ANCHO DE CALZADA: PENDIENTE GOBERNADORA: ANCHO DE CORONA: 7 MTS. CARACTERISTICAS PLANO: ARCHIVO: REVISO: LEVANTO: FECHA: TOP. BULMARO PRIETO AGOSTO /2010 NUM: 1:100 ACOTACIONES : ESCALA: GRAFICOS: PROYECTO: DEPARTAMENTO DE PROYECTOS: SECCIONES DEL KM 0+000 AL KM 0+360 EN METROS. P-1 G U E R R E R O \A1;CORONA = 7.00 m 3.50 3.50 \A1;1.00 0.00 0.00 ESTRUCTURA DEL PAVIMENTO CORTE CARPETA 1/4:1 TERRACERIA EXISTENTE TERRENO NATURAL 3:1 LINEA SUBRASANTE DE PROYECTO TERRAPLEN 1.5:1 EJE DE PROYECTO L C SECCION TIPO 0.05 0.20 0.30 BASE SUBRASANTE META: 3.02 KM DE ESTACION: KM 0+000 AL 3+020 CAMINO: LA CONCEPCION - QUIAHUITLATZALA REGION: 04 - MONTAÑA DATOS DEL PROYECTO: D 40 KM/HR. DEL TRAMO CONCEPTO: CAMINO TIPO: VELOCIDAD DE PROYECTO: 60° 20 CMS. 6 MTS. 12.00 % 8.00 % ESPESOR DE BASE: CURVATURA MAXIMA: PENDIENTE MAXIMA: ANCHO DE CALZADA: PENDIENTE GOBERNADORA: ANCHO DE CORONA: 7 MTS. CARACTERISTICAS PLANO: ARCHIVO: REVISO: LEVANTO: FECHA: TOP. BULMARO PRIETO AGOSTO /2010 NUM: 1:100 ACOTACIONES : ESCALA: GRAFICOS: PROYECTO: DEPARTAMENTO DE PROYECTOS: SECCIONES DEL KM 0+000 AL KM 0+360 EN METROS. P-1 G U E R R E R O \A1;CORONA = 7.00 m 3.50 3.50 \A1;1.00 0.00 0.00 Y=800 Y=900 Y=1,000 Y=1,100 Y=1,200 Y=1,300 Y=1,400 Y=1,500 Y=1,600 Y=1,700 Y=1,800 Y=1,900 Y=2,000 Y=2,100 Y=2,200 Y=2,300 Y=2,400 Y=2,500 Y=2,600 Y=2,700 Y=2,800 X=2,900 X=3,000 X=3,100 X=3,200 X=3,300 X=3,400 X=3,500 X=3,600 X=3,700 X=3,800 X=3,900 X=4,000 X=4,100 X=4,200 X=4,300 X=4,400 X=4,500 DE ESTACION: KM 0+000 AL 1+940 CAMINO: COPALA - ATRIXCO REGION: DATOS DEL PROYECTO: C 40 KM/HR. DEL TRAMO CONCEPTO: CAMINO TIPO: VELOCIDAD DE PROYECTO: 30° 20 CMS. 6 MTS. 8.00% 6.0 % ESPESOR DE BASE: CURVATURA MAXIMA: PENDIENTE MAXIMA: ANCHO DE CALZADA: PENDIENTE GOBERNADORA: ANCHO DE CORONA: 7 MTS. CARACTERISTICAS PLANO: ARCHIVO: REVISO: LEVANTO: FECHA: AGOSTO /2010 NUM: ACOTACIONES : ESCALA: GRAFICOS: PROYECTO: DEPARTAMENTO DE PROYECTOS: PLANTA (ALINEAMIENTO HORIZONTAL) EN METROS. G U E R R E R O EJE DE PROYECTO DERECHO DE VIA D = 6°4'0.00" der ST = 20.241 PI = 0+163.49 Gc = 3°0'0.00" Lc = 40.444 Rc = 381.972 Sc = 2.50% Ac = 0.40 Le entrada = 22.40 Le salida = 22.40 PC=0+143.25 PT=0+183.70 D = 4°46'0.00" der ST = 23.764 PI = 0+280.50 Gc = 2°0'0.00" Lc = 47.500 Rc = 572.958 Sc = 2.00% Ac = 0.30 Le entrada = 10.00 Le salida = 10.00 PC=0+256.73 PT=0+304.23 D = 12°14'0.00" izq ST = 20.467 PI = 0+347.19 Gc = 6°0'0.00" Lc = 40.778 Rc = 190.986 Sc = 4.50% Ac = 0.60 Le entrada = 7.90 Le salida = 7.90 PC=0+326.72 PT=0+367.50 D = 14°10'0.00" izq ST = 20.342 PI = 0+645.58 Gc = 7°0'0.00" Lc = 40.476 Rc = 163.702 Sc = 5.10% Ac = 0.70 Le entrada = 22.40 Le salida = 22.40 PC=0+625.24 PT=0+665.72 D = 27°30'0.00" der ST = 20.029 PI = 0+769.64 Gc = 14°0'0.00" Lc = 39.286 Rc = 81.851 Sc = 7.90% Ac = 1.10 Le entrada = 25.43 Le salida = 25.43 PC=0+749.61 PT=0+788.89 D = 26°26'0.00" der ST = 20.702 PI = 0+856.74 Gc = 13°0'0.00" Lc = 40.667 Rc = 88.147 Sc = 7.60% Ac = 1.00 Le entrada = 24.44 Le salida = 24.44 PC=0+836.04 PT=0+876.71 D = 12°10'0.00" der ST = 20.354 PI = 0+934.40 Gc = 6°0'0.00" Lc = 40.556 Rc = 190.986 Sc = 4.50% Ac = 0.60 Le entrada = 19.00 Le salida = 19.00 PC=0+914.04 PT=0+954.60 D = 27°46'0.00" izq ST = 21.787 PI = 1+029.99 Gc = 13°0'0.00" Lc = 42.718 Rc = 88.147 Sc = 7.60% Ac = 1.00 Le entrada = 24.44 Le salida = 24.44 PC=1+008.21 PT=1+050.92 D = 56°0'0.00" izq ST = 26.491 PI = 1+127.89 Gc = 23°0'0.00" Lc = 48.696 Rc = 49.822 Sc = 9.60% Ac = 1.50 Le entrada = 30.71 Le salida = 30.71 PC=1+101.40 PT=1+150.09 D = 17°4'0.00" der ST = 21.492 PI = 1+302.09 Gc = 8°0'0.00" Lc = 42.667 Rc = 143.239 Sc = 5.60% Ac = 0.70 Le entrada = 22.40 Le salida = 22.40 PC=1+280.60 PT=1+323.27 D = 12°30'0.00" izq ST = 20.916 PI = 1+423.39 Gc = 6°0'0.00" Lc = 41.667 Rc = 190.986 Sc = 4.50% Ac = 0.60 Le entrada = 22.40 Le salida = 22.40 PC=1+402.48 PT=1+444.14 D = 10°40'0.00" der ST = 21.395 PI = 1+575.29 Gc = 5°0'0.00" Lc = 42.667 Rc = 229.183 Sc = 3.90% Ac = 0.50 Le entrada = 22.40 Le salida = 22.40 PC=1+553.89 PT=1+596.56 D = 31°16'0.10" der ST = 21.378 PI = 1+917.08 Gc = 15°0'0.00" Lc = 41.689 Rc = 76.394 Sc = 8.20% Ac = 1.10 Le entrada = 3.00 Le salida = 3.00 PC=1+895.71 PT=1+937.39 143.26m S 34°00'00.00" W 73.04m S 40°04'00.00" W 22.49m S 44°50'00.00" W 257.74m S 32°36'00.00" W 83.89m S 18°26'00.00" W 47.15m S 45°56'00.00" W 37.33m S 72°22'00.00" W 53.61m S 84°32'00.00" W 50.47m S 56°46'00.00" W 130.51m S 00°45'59.99" W 79.21m S 17°50'00.00" W 109.75m S 05°20'00.00" W 299.15m S 16°00'00.00" W 2.66m S 47°16'00.10" W 0+000.00 0+100.00 0+200.00 0+300.00 0+400.00 0+500.00 0+600.00 0+700.00 0+800.00 0+900.00 1+000.00 1+100.00 1+200.00 1+300.00 1+400.00 1+500.00 1+600.00 1+700.00 1+800.00 1+900.00 Y=800 Y=900 Y=1,000 Y=1,100 Y=1,200 Y=1,300 Y=1,400 Y=1,500 Y=1,600 Y=1,700 Y=1,800 Y=1,900 Y=2,000 Y=2,100 Y=2,200 Y=2,300 Y=2,400 Y=2,500 Y=2,600 Y=2,700 Y=2,800 X=3,000 X=3,100 X=3,200 X=3,300 X=3,400 X=3,500 X=3,600 X=3,700 X=3,800 X=3,900 X=4,000 X=4,100 X=4,200 X=4,300 X=4,400 X=4,500 143.26m S 34°00'00.00" W 73.04m S 40°04'00.00" W 22.49m S 44°50'00.00" W 257.74m S 32°36'00.00" W 83.89m S 18°26'00.00" W 47.15m S 45°56'00.00" W 37.33m S 72°22'00.00" W 53.61m S 84°32'00.00" W 50.47m S 56°46'00.00" W 130.51m S 00°45'59.99" W 79.21m S 17°50'00.00" W 109.75m S 05°20'00.00" W 299.15m S 16°00'00.00" W 2.66m S 47°16'00.10" W D = 6°4'0.00" der ST = 20.241 PI = 0+163.49 Gc = 3°0'0.00" Lc = 40.444 Rc = 381.972 Sc = 2.50% Ac = 0.40 Le entrada = 22.40 Le salida = 22.40 PC=0+143.25 PT=0+183.70 D = 4°46'0.00" der ST = 23.764 PI = 0+280.50 Gc = 2°0'0.00" Lc = 47.500 Rc = 572.958 Sc = 2.00% Ac = 0.30 Le entrada = 10.00 Le salida = 10.00 PC=0+256.73 PT=0+304.23 D = 12°14'0.00" izq ST = 20.467 PI = 0+347.19 Gc = 6°0'0.00" Lc = 40.778 Rc = 190.986 Sc = 4.50% Ac = 0.60 Le entrada = 7.90 Le salida = 7.90 PC=0+326.72 PT=0+367.50 D = 14°10'0.00" izq ST = 20.342 PI = 0+645.58 Gc = 7°0'0.00" Lc = 40.476 Rc = 163.702 Sc = 5.10% Ac = 0.70 Le entrada = 22.40 Le salida = 22.40 PC=0+625.24 PT=0+665.72 D = 27°30'0.00" der ST = 20.029 PI = 0+769.64 Gc = 14°0'0.00" Lc = 39.286 Rc = 81.851 Sc = 7.90% Ac = 1.10 Le entrada = 25.43 Le salida = 25.43 PC=0+749.61 PT=0+788.89 D = 26°26'0.00" der ST = 20.702 PI = 0+856.74 Gc = 13°0'0.00" Lc = 40.667 Rc = 88.147 Sc = 7.60% Ac = 1.00 Le entrada = 24.44 Le salida = 24.44 PC=0+836.04 PT=0+876.71 D = 12°10'0.00" der ST = 20.354 PI = 0+934.40 Gc = 6°0'0.00" Lc = 40.556 Rc = 190.986 Sc = 4.50% Ac = 0.60 Le entrada = 19.00 Le salida = 19.00 PC=0+914.04 PT=0+954.60 D = 27°46'0.00" izq ST = 21.787 PI = 1+029.99 Gc = 13°0'0.00" Lc = 42.718 Rc = 88.147 Sc = 7.60% Ac = 1.00 Le entrada = 24.44 Le salida = 24.44 PC=1+008.21 PT=1+050.92 D = 56°0'0.00" izq ST = 26.491 PI = 1+127.89 Gc = 23°0'0.00" Lc = 48.696 Rc = 49.822 Sc = 9.60% Ac = 1.50 Le entrada = 30.71 Le salida = 30.71 PC=1+101.40 PT=1+150.09 D = 17°4'0.00" der ST = 21.492 PI = 1+302.09 Gc = 8°0'0.00" Lc = 42.667 Rc = 143.239 Sc = 5.60% Ac = 0.70 Le entrada = 22.40 Le salida = 22.40 PC=1+280.60 PT=1+323.27 D = 12°30'0.00" izq ST = 20.916 PI = 1+423.39 Gc = 6°0'0.00" Lc = 41.667 Rc = 190.986 Sc = 4.50% Ac = 0.60 Le entrada = 22.40 Le salida = 22.40 PC=1+402.48 PT=1+444.14 D = 10°40'0.00" der ST = 21.395 PI = 1+575.29 Gc = 5°0'0.00" Lc = 42.667 Rc = 229.183 Sc = 3.90% Ac = 0.50 Le entrada = 22.40 Le salida = 22.40 PC=1+553.89 PT=1+596.56 D = 31°16'0.10" der ST = 21.378 PI = 1+917.08 Gc = 15°0'0.00" Lc = 41.689 Rc = 76.394 Sc = 8.20% Ac = 1.10 Le entrada = 3.00 Le salida = 3.00 PC=1+895.71 PT=1+937.39 X=3,000 X=3,100 X=3,200 X=3,300 X=3,400 X=3,500 X=3,600 X=3,700 X=3,800 X=3,900 X=4,000 X=4,100 X=4,200 X=4,300 X=4,400 X=4,500 Y=2,800 Y=2,700 Y=2,600 Y=2,500 Y=2,400 Y=2,300 Y=2,200 Y=2,100 Y=2,000 Y=1,900 Y=1,800 Y=1,700 Y=1,600 Y=1,500 Y=1,400 Y=1,300 Y=1,200 Y=1,100 Y=1,000 Y=900 Y=800 C1 C2 C3 C4 C5 C6 C7 C8 C9 C10 C11 C12 C13 CUADRO DE CURVAS CURVA DELTA RADIO ARCO STAN CUERDA Gc RUMBO CUERDA C1 06°4'0.00" 381.972 40.444 20.241 40.426 03°0'0" S 37°02'00.00" W C2 04°46'0.00" 570.952 47.500 23.764 47.486 02°0'25" S 42°27'00.00" W C3 12°14'0.00" 190.986 40.778 20.467 40.700 06°0'0" N 38°43'00.00" E C4 14°10'0.00" 163.702 40.476 20.342 40.373 07°0'0" N 25°31'00.00" E C5 27°30'0.00" 81.851 39.286 20.029 38.910 14°0'0" S 32°11'00.00" W C6 26°26'0.00" 88.147 40.667 20.702 40.307 13°0'0" S 59°09'00.00" W C7 12°10'0.00" 190.986 40.556 20.354 40.479 06°0'0" S 78°27'00.00" W C8 27°46'0.00" 88.147 42.718 21.787 42.301 13°0'0" N 70°39'00.00" E C9 56°0'0.00" 49.822 48.696 26.491 46.780 23°0'0" N 28°45'59.99" E C10 17°4'0.00" 143.239 42.667 21.492 42.509 08°0'0" S 09°18'00.00" W C11 12°30'0.00" 190.986 41.667 20.916 41.584 06°0'0" N 11°35'00.00" E C12 10°40'0.00" 229.183 42.667 21.395 42.605 05°0'0" S 10°40'00.00" W C13 31°16'0.10" 76.394 41.689 21.378 41.174 15°0'0" S 31°38'00.05" W C1 C2 C3 C4 C5 C6 C7 C8 C9 C10 C11 C12 C13 C1 C2 C3 C4 C5 C6 C7 C8 C9 C10 C11 C12 C13 CUADRO DE CONSTRUCCION DE EJE LADO DISTANCIA RUMBO V X Y COORDENADAS EST PV PST=0+000.00 4,291.2850 2,566.8226 PST=0+000.00 PC=0+143.25 S 34°00'00.00" W 143.258 PC=0+143.25 4,211.1762 2,448.0564 PC=0+143.25 PT=0+183.70 S 37°02'00.00" W 40.426 PT=0+183.70 4,186.8287 2,415.7853 D = 6°4'0.00" der Lc = 40.444 PI=0+163.49 4,199.8575 2,431.2757 Rc = 381.972 ST = 20.241 PT=0+183.70 PC=0+256.73 S 40°04'00.00" W 73.035 PC=0+256.73 4,139.8175 2,359.8917 PC=0+256.73 PT=0+304.23 S 42°27'00.00" W 47.486 PT=0+304.23 4,107.7669 2,324.8533 D = 4°46'0.00" der Lc = 47.500 PI=0+280.50 4,124.5214 2,341.7055 Rc = 572.958 ST = 23.764 PT=0+304.23 PC=0+326.72 S 44°50'00.00" W 22.490 PC=0+326.72 4,091.9106 2,308.9045 PC=0+326.72 PT=0+367.50 S 38°43'00.00" W 40.700 PT=0+367.50 4,066.4538 2,277.1481 D = 12°14'0.00" izq Lc = 40.778 PI=0+347.19 4,077.4806 2,294.3903 Rc = 190.986 ST = 20.467 PT=0+367.50 PC=0+625.24 S 32°36'00.00" W 257.741 PC=0+625.24 3,927.5902 2,060.0132 PC=0+625.24 PT=0+665.72 S 25°31'00.00" W 40.373 PT=0+665.72 3,910.1985 2,023.5780 D = 14°10'0.00" izq Lc = 40.476 PI=0+645.58 3,916.6306 2,042.8761 Rc = 163.702 ST = 20.342 PT=0+665.72 PC=0+749.61 S 18°26'00.00" W 83.889 PC=0+749.61 3,883.6726 1,943.9928 PC=0+749.61 PT=0+788.89 S 32°11'00.00" W 38.910 PT=0+788.89 3,862.9482 1,911.0617 D = 27°30'0.00" der Lc = 39.286 PI=0+769.64 3,877.3395 1,924.9916 Rc = 81.851 ST = 20.029 PT=0+788.89 PC=0+836.04 S 45°56'00.00" W 47.149 PC=0+836.04 3,829.0699 1,878.2696 PC=0+836.04 PT=0+876.71 S 59°09'00.00" W 40.307 PT=0+876.71 3,794.4658 1,857.6005 D = 26°26'0.00" der Lc = 40.667 PI=0+856.74 3,814.1950 1,863.8715 Rc = 88.147 ST = 20.702 PT=0+876.71 PC=0+914.04 S 72°22'00.00" W 37.334 PC=0+914.04 3,758.8861 1,846.2911 PC=0+914.04 PT=0+954.60 S 78°27'00.00" W 40.479 PT=0+954.60 3,719.2264 1,838.1862 D = 12°10'0.00" der Lc = 40.556 PI=0+934.40 3,739.4882 1,840.1253 Rc = 190.986 ST = 20.354 PT=0+954.60 PC=1+008.21 S 84°32'00.00" W 53.609 PC=1+008.21 3,665.8616 1,833.0791 PC=1+008.21 PT=1+050.92 S 70°39'00.00" W 42.301 PT=1+050.92 3,625.9500 1,819.0631 D = 27°46'0.00" izq Lc = 42.718 PI=1+029.99 3,644.1737 1,831.0035 Rc = 88.147 ST = 21.787 PT=1+050.92 PC=1+101.40 S 56°46'00.00" W 50.472 PC=1+101.40 3,583.7330 1,791.4020 PC=1+101.40 PT=1+150.09 S 28°45'59.99" W 46.780 PT=1+150.09 3,561.2202 1,750.3949 D = 56°0'0.00" izq Lc = 48.696 PI=1+127.89 3,561.5747 1,776.8836 Rc = 49.822 ST = 26.491 PT=1+150.09 PC=1+280.60 S 00°45'59.99" W 130.506 PC=1+280.60 3,559.4740 1,619.9001 PC=1+280.60 PT=1+323.27 S 09°18'00.00" W 42.509 PT=1+323.27 3,552.6043 1,577.9498 D = 17°4'0.00" der Lc = 42.667 PI=1+302.09 3,559.1864 1,598.4096 Rc = 143.239 ST = 21.492 PT=1+323.27 PC=1+402.48 S 17°50'00.00" W 79.211 PC=1+402.48 3,528.3460 1,502.5446 PC=1+402.48 PT=1+444.14 S 11°35'00.00" W 41.584 PT=1+444.14 3,519.9962 1,461.8074 D = 12°30'0.00" izq Lc = 41.667 PI=1+423.39 3,521.9404 1,482.6332 Rc = 190.986 ST = 20.916 PT=1+444.14 PC=1+553.89 S 05°20'00.00" W 109.748 PC=1+553.89 3,509.7951 1,352.5341 PC=1+553.89 PT=1+596.56 S 10°40'00.00" W 42.605 PT=1+596.56 3,501.9091 1,310.6652 D = 10°40'0.00" der Lc = 42.667 PI=1+575.29 3,507.8064 1,331.2315 Rc = 229.183 ST = 21.395 PT=1+596.56 PC=1+895.71 S 16°00'00.00" W 299.147 PC=1+895.71 3,419.4530 1,023.1064 PC=1+895.71 PT=1+937.39 S 31°38'00.05" W 41.174 PT=1+937.39 3,397.8582 988.0504 D = 31°16'0.10" der Lc = 41.689 PI=1+917.08 3,413.5605 1,002.5569 Rc = 76.394 ST = 21.378 PT=1+937.39 PST=1+940.05 S 47°16'00.10" W 2.656 PST=1+940.05 3,395.9072 986.2480 LONGITUD = 1,940.055m 55 50 45 40 35 30 TIPO DE MATERIAL FACTOR DE ABUNDAMIENTO FACTOR DE COMPACTACION ORDENADAS DE LA CURVA MASA TERRAPLEN CORTE TERRAPLEN CORTE SUBRASANTE TERRENO VOLUMEN ESPESOR ELEVACION ESCALA HORIZONTAL 1 : 2000 ESCALA VERTICAL 1 : 200 PERFIL -4.80 % en 10.00m PCV=0+009.99 Elev=43.12 PIV=0+019.99 Elev=42.64 PTV=0+029.99 Elev=42.31 -3.30 % en 10.00m PCV=0+040.00 Elev=41.98 PIV=0+060.00 Elev=41.32 PTV=0+080.00 Elev=41.18 -0.70 % en 40.00m PCV=0+120.00 Elev=40.90 PIV=0+140.00 Elev=40.76 PTV=0+160.00 Elev=41.00 +1.20 % en 40.00m PCV=0+200.00 Elev=41.48 PIV=0+220.00 Elev=41.72 PTV=0+240.00 Elev=42.68 +4.80 % en 60.00m PCV=0+300.00 Elev=45.56 PIV=0+320.00 Elev=46.52 PTV=0+340.00 Elev=46.62 +0.50 % en 20.00m PCV=0+360.00 Elev=46.72 PIV=0+380.00 Elev=46.82 PTV=0+400.00 Elev=46.12 -3.50 % en 40.00m PCV=0+440.00 Elev=44.72 PIV=0+460.00 Elev=44.02 PTV=0+480.00 Elev=42.86 -5.80 % en 20.00m PCV=0+500.00 Elev=41.70 PIV=0+520.00 Elev=40.54 PTV=0+540.00 Elev=39.87 -3.37 % en 60.00m PCV=0+600.00 Elev=37.85 PIV=0+630.00 Elev=36.83 PTV=0+660.00 Elev=37.66 +2.76 % en 10.00m PCV=0+670.00 Elev=37.94 PIV=0+690.00 Elev=38.49 PTV=0+710.00 Elev=38.51 +0.10 % en 10.00m PCV=0+720.00 Elev=38.52 PIV=0+740.00 Elev=38.54 PTV=0+760.00 Elev=38.06 -2.40 % en 20.00m PCV=0+780.00 Elev=37.58 PIV=0+810.00 Elev=36.86 PTV=0+840.00 Elev=37.85 +3.29 % en 60.00m PCV=0+900.00 Elev=39.82 PIV=0+920.00 Elev=40.48 PTV=0+940.00 Elev=40.60 +0.60 % en 80.00m PCV=1+020.00 Elev=41.08 PIV=1+040.00 Elev=41.20 PTV=1+060.00 Elev=41.00 -1.00 % en 50.00m PCV=1+110.00 Elev=40.50 PIV=1+130.00 Elev=40.30 PTV=1+150.00 Elev=40.52 +1.10 % en 70.00m PCV=1+220.00 Elev=41.29 PIV=1+240.00 Elev=41.51 PTV=1+260.00 Elev=41.49 -0.10 % en 80.00m PCV=1+340.00 Elev=41.41 PIV=1+360.00 Elev=41.39 PTV=1+380.00 Elev=41.71 +1.60 % en 80.00m PCV=1+460.00 Elev=42.99 PIV=1+480.00 Elev=43.31 PTV=1+500.00 Elev=44.19 +4.40 % en 40.00m PCV=1+540.00 Elev=45.95 PIV=1+560.00 Elev=46.83 PTV=1+580.00 Elev=47.01 +0.90 % en 40.00m PCV=1+620.00 Elev=47.37 PIV=1+640.00 Elev=47.55 PTV=1+660.00 Elev=47.25 PCV=1+660.00 Elev=47.25 PIV=1+680.00 Elev=46.95 PTV=1+700.00 Elev=47.13 +0.90 % en 90.00m PCV=1+790.00 Elev=47.94 PIV=1+810.00 Elev=48.12 PTV=1+830.00 Elev=47.78 -1.70 % en 50.00m PCV=1+880.00 Elev=46.93 PIV=1+900.00 Elev=46.59 PTV=1+920.00 Elev=46.67 +0.40 % en 20.05m 0+000.00 10,000 0.00 0.00 0.25 43.60 43.85 0+020.00 9,991 0.41 45.24 0.04 42.68 42.64 0+040.00 9,948 2.08 13.08 0.13 41.98 41.85 0+060.00 9,902 2.41 8.84 0.14 41.45 41.31 0+080.00 9,849 4.90 5.28 0.17 41.18 41.01 0+100.00 9,787 13.32 0.06 0.22 41.04 40.82 0+120.00 9,723 15.40 0.00 0.16 40.90 40.74 0+140.00 9,668 9.54 3.33 0.07 40.85 40.78 0+160.00 9,611 8.31 4.03 0.15 41.00 40.85 0+180.00 9,546 14.78 0.71 0.21 41.24 41.03 0+200.00 9,481 15.63 0.01 0.20 41.48 41.28 0+220.00 9,420 11.53 0.00 0.18 41.90 41.72 0+240.00 9,353 18.86 0.02 0.34 42.68 42.34 0+260.00 9,291 16.72 4.17 0.09 43.64 43.55 0+280.00 9,251 3.59 15.81 0.04 44.60 44.64 0+300.00 9,241 0.47 43.28 0.28 45.56 45.84 0+320.00 9,302 0.42 117.36 0.78 46.30 47.08 0+340.00 9,455 0.41 206.64 1.08 46.62 47.70 0+360.00 9,622 0.41 226.30 0.87 46.72 47.59 0+380.00 9,704 0.41 139.66 0.22 46.62 46.84 0+400.00 9,708 0.42 58.79 0.15 46.12 46.27 0+420.00 9,711 0.42 57.08 0.27 45.42 45.69 0+440.00 9,728 0.41 70.49 0.30 44.72 45.02 0+460.00 9,736 0.41 62.25 0.12 43.91 44.03 0+480.00 9,707 0.64 25.50 0.11 42.86 42.75 0+500.00 9,657 3.01 1.18 0.12 41.70 41.58 0+520.00 9,605 3.72 0.00 0.10 40.66 40.56 0+540.00 9,558 1.22 3.15 0.09 39.87 39.78 0+560.00 9,517 0.16 9.52 0.05 39.19 39.14 0+580.00 9,469 1.69 7.28 0.12 38.52 38.40 0+600.00 9,408 13.84 0.90 0.35 37.85 37.50 0+620.00 9,347 13.74 1.47 0.11 37.38 37.27 0+640.00 9,280 19.35 1.54 0.29 37.31 37.02 0+660.00 9,146 81.58 0.07 0.73 37.66 36.93 0+680.00 8,960 133.49 0.00 0.43 38.18 37.75 0+700.00 8,797 113.84 0.00 0.26 38.47 38.21 0+720.00 8,645 104.96 2.43 0.11 38.52 38.41 0+740.00 7,856 756.75 17.42 0.18 38.42 38.60 0+760.00 7,055 766.11 14.99 0.45 38.06 37.61 0+780.00 6,873 126.36 0.00 0.49 37.58 37.09 0+800.00 6,745 72.57 0.00 0.30 37.29 36.99 0+820.00 6,675 20.20 0.06 0.18 37.38 37.20 0+840.00 6,598 29.26 0.10 0.35 37.85 37.50 0+860.00 6,475 70.31 0.04 0.53 38.51 37.98 0+880.00 6,330 90.14 0.00 0.49 39.16 38.67 0+900.00 6,237 46.15 5.08 0.08 39.82 39.74 0+920.00 6,228 1.05 46.08 0.30 40.35 40.65 0+940.00 6,244 0.39 73.45 0.22 40.60 40.82 0+960.00 6,336 0.36 150.34 1.01 40.72 41.73 0+980.00 6,414 0.37 132.50 0.02 40.84 40.86 1+000.00 6,383 5.95 29.50 0.04 40.96 41.00 1+020.00 6,386 5.97 63.05 0.29 41.08 41.37 1+040.00 6,359 14.98 48.71 0.22 41.12 40.90 1+060.00 6,261 44.47 0.55 0.45 41.00 40.55 1+080.00 6,147 63.28 0.00 0.50 40.80 40.30 1+100.00 6,028 70.46 0.00 0.41 40.60 40.19 1+120.00 5,918 66.61 10.65 0.23 40.43 40.20 1+140.00 5,812 57.83 11.99 0.27 40.44 40.17 1+160.00 5,710 44.47 1.33 0.29 40.63 40.34 1+180.00 5,610 48.72 0.00 0.50 40.85 40.35 1+200.00 5,497 63.68 0.00 0.45 41.07 40.62 1+220.00 5,373 74.60 0.00 0.59 41.29 40.70 1+240.00 5,216 107.34 0.00 0.72 41.45 40.73 1+260.00 5,053 113.97 0.00 0.61 41.49 40.88 1+280.00 4,918 85.76 0.00 0.49 41.47 40.98 1+300.00 4,832 65.62 30.78 0.56 41.45 40.89 1+320.00 4,763 45.02 32.12 0.30 41.43 41.13 1+340.00 4,698 15.27 4.72 0.09 41.41 41.32 1+360.00 4,664 0.16 12.77 0.06 41.48 41.42 1+380.00 4,622 0.36 12.47 0.12 41.71 41.59 1+400.00 4,567 11.93 4.43 0.27 42.03 41.76 1+420.00 4,503 22.47 7.85 0.21 42.35 42.14 1+440.00 4,428 28.62 8.50 0.32 42.67 42.35 1+460.00 4,346 30.28 2.65 0.30 42.99 42.69 1+480.00 4,273 27.23 2.23 0.34 43.45 43.11 1+500.00 4,186 40.15 4.34 0.48 44.19 43.71 1+520.00 4,078 59.56 2.77 0.50 45.07 44.57 1+540.00 3,969 59.69 0.00 0.40 45.95 45.55 1+560.00 3,895 27.49 3.37 0.10 46.65 46.55 1+580.00 3,893 2.24 53.61 0.41 47.01 47.42 1+600.00 3,975 0.40 139.24 0.78 47.19 47.97 1+620.00 4,061 0.40 142.17 0.43 47.37 47.80 1+640.00 4,056 4.76 53.22 0.19 47.43 47.24 1+660.00 3,958 49.08 0.05 0.61 47.25 46.64 1+680.00 3,796 112.63 0.00 0.86 47.07 46.21 1+700.00 3,581 165.64 0.00 0.92 47.13 46.21 1+720.00 3,388 143.67 0.00 0.61 47.31 46.70 1+740.00 3,276 62.33 0.00 0.34 47.49 47.15 1+760.00 3,190 37.61 0.00 0.40 47.67 47.27 1+780.00 3,056 84.12 0.00 0.83 47.85 47.02 1+800.00 2,839 167.53 0.00 1.22 48.00 46.78 1+820.00 2,566 224.13 0.00 1.26 47.92 46.66 1+840.00 2,337 179.75 0.00 0.77 47.61 46.84 1+860.00 2,208 79.27 0.00 0.35 47.27 46.92 1+880.00 2,152 18.99 13.11 0.01 46.93 46.92 1+900.00 2,140 2.65 44.15 0.14 46.69 46.83 1+920.00 2,131 4.49 53.00 0.09 46.67 46.76 1+940.00 2,105 6.67 38.89 0.25 46.75 47.00 TOTAL VOLUMEN CORTE = 2,407.74m3 TOTAL VOLUMEN TERRAPLEN = -10,302.89m3 TOTAL VOLUMEN DESPALME EN CORTE = 3,384.58m3 TOTAL VOLUMEN DESPALME EN TERRAPLEN = -1,496.45m3 A 1.000 1.000 AZ=214°0'0.00" TAN=143.26m D = 6°4'0.00" der ST = 20.241 PI = 0+163.49 Gc = 3°0'0.00" Lc = 40.444 Rc = 381.972 Sc = 2.50% Ac = 0.40 Le entrada = 22.40 Le salida = 22.40 PC=0+143.25 PT=0+183.70 AZ=220°4'0.00" TAN=73.04m D = 4°46'0.00" der ST = 23.764 PI = 0+280.50 Gc = 2°0'0.00" Lc = 47.500 Rc = 572.958 Sc = 2.00% Ac = 0.30 Le entrada = 10.00 Le salida = 10.00 PC=0+256.73 PT=0+304.23 AZ=224°50'0.00" TAN=22.49m D = 12°14'0.00" izq ST = 20.467 PI = 0+347.19 Gc = 6°0'0.00" Lc = 40.778 Rc = 190.986 Sc = 4.50% Ac = 0.60 Le entrada = 7.90 Le salida = 7.90 PC=0+326.72 PT=0+367.50 AZ=212°36'0.00" TAN=257.74m D = 14°10'0.00" izq ST = 20.342 PI = 0+645.58 Gc = 7°0'0.00" Lc = 40.476 Rc = 163.702 Sc = 5.10% Ac = 0.70 Le entrada = 22.40 Le salida = 22.40 PC=0+625.24 PT=0+665.72 AZ=198°26'0.00" TAN=83.89m D = 27°30'0.00" der ST = 20.029 PI = 0+769.64 Gc = 14°0'0.00" Lc = 39.286 Rc = 81.851 Sc = 7.90% Ac = 1.10 Le entrada = 25.43 Le salida = 25.43 PC=0+749.61 PT=0+788.89 AZ=225°56'0.00" TAN=47.15m D = 26°26'0.00" der ST = 20.702 PI = 0+856.74 Gc = 13°0'0.00" Lc = 40.667 Rc = 88.147 Sc = 7.60% Ac = 1.00 Le entrada = 24.44 Le salida = 24.44 PC=0+836.04 PT=0+876.71 AZ=252°22'0.00" TAN=37.33m D = 12°10'0.00" der ST = 20.354 PI = 0+934.40 Gc = 6°0'0.00" Lc = 40.556 Rc = 190.986 Sc = 4.50% Ac = 0.60 Le entrada = 19.00 Le salida = 19.00 PC=0+914.04 PT=0+954.60 AZ=264°32'0.00" TAN=53.61m D = 27°46'0.00" izq ST = 21.787 PI = 1+029.99 Gc = 13°0'0.00" Lc = 42.718 Rc = 88.147 Sc = 7.60% Ac = 1.00 Le entrada = 24.44 Le salida = 24.44 PC=1+008.21 PT=1+050.92 AZ=236°46'0.00" TAN=50.47m D = 56°0'0.00" izq ST = 26.491 PI = 1+127.89 Gc = 23°0'0.00" Lc = 48.696 Rc = 49.822 Sc = 9.60% Ac = 1.50 Le entrada = 30.71 Le salida = 30.71 PC=1+101.40 PT=1+150.09 AZ=180°45'59.99" TAN=130.51m D = 17°4'0.00" der ST = 21.492 PI = 1+302.09 Gc = 8°0'0.00" Lc = 42.667 Rc = 143.239 Sc = 5.60% Ac = 0.70 Le entrada = 22.40 Le salida = 22.40 PC=1+280.60 PT=1+323.27 AZ=197°50'0.00" TAN=79.21m D = 12°30'0.00" izq ST = 20.916 PI = 1+423.39 Gc = 6°0'0.00" Lc = 41.667 Rc = 190.986 Sc = 4.50% Ac = 0.60 Le entrada = 22.40 Le salida = 22.40 PC=1+402.48 PT=1+444.14 AZ=185°20'0.00" TAN=109.75m D = 10°40'0.00" der ST = 21.395 PI = 1+575.29 Gc = 5°0'0.00" Lc = 42.667 Rc = 229.183 Sc = 3.90% Ac = 0.50 Le entrada = 22.40 Le salida = 22.40 PC=1+553.89 PT=1+596.56 AZ=196°0'0.00" TAN=299.15m D = 31°16'0.10" der ST = 21.378 PI = 1+917.08 Gc = 15°0'0.00" Lc = 41.689 Rc = 76.394 Sc = 8.20% Ac = 1.10 Le entrada = 3.00 Le salida = 3.00 PC=1+895.71 PT=1+937.39
