Sanitary Register DWG Detail for AutoCAD

Sanitary Register DWG Detail for AutoCAD

Details – specifications – axonometric

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Sanitary registry detail esc, Clay brick, Concrete block, For registration cover., Concrete seat, Tube in half cane., Tube in half cane, For solid waste., Concrete base with, Slope towards, Discharge tube, Diam., Concrete reinforced with vr, Cms in both directions, Registration cover made of

Raw text data extracted from CAD file:

DETALLE DE REGISTRO SANITARIO ESC 1:20 LADRILLO DE ARCILLA O BLOCK DE CONCRETO DE 4" PARA TAPA DE REGISTRO. ASIENTO DE CONCRETO TUBO EN MEDIA CANA. TUBO EN MEDIA CANA PARA DESECHO DE SOLIDOS. BASE DE CONCRETO CON PENDIENTE HACIA EL TUBO DE DESCARGA DE 4" O 6" DIAM. CONCRETO ARMADO CON VR 3/8" @ 10 CMS EN AMBOS SENTIDOS TAPA DE REGISTRO HECHA DE

Language	Spanish
Drawing Type	Detail
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials	Concrete
