Section By Facade Windows And Inclined Flagstone DWG Section for AutoCAD

Section By Facade Windows And Inclined Flagstone DWG Section for AutoCAD

Constructive detail – window and inclined flagstone of Qualy panel – Covintec- Structuring

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

variable, no. reinforcement for covintec lashing, projection of reinforced concrete column, remove the necessary polystyrene strips filled with concrete, in slanted slab windows, cut by facade, shoe, armed, castle, projection, n.jardin, block, in addition to, molding made with covintec anchored the qualy slab, variable, cancel aluminum with clear glass esp. mm shatterproof, wall of covintec, n.t.n., n.p.t., see detail no., thick concrete, reinforced concrete block, arq. lizbeth luis tuxtla chiapas

Raw text data extracted from CAD file:

Variable Varilla del No. 3 de refuerzo para amarre de covintec Proyección de columna de concreto armado Retirar las tiras de poliestireno necesarias y rellenar con concreto EN VENTANAS Y LOSA INCLINADA CORTE POR FACHADA CT ZAPATA ARMADO DE CASTILLO PROYECCION N.JARDIN 0+000 BLOCK ENRASE DE Moldura hecha con covintec anclado a la qualy losa Variable Cancel de aluminio con vidrio transparente esp. 6 mm inastillable Muro de covintec de 3" CD-1 N.T.N. N.P.T. +0.35 Ver detalle No. 4 Concreto de 5cm de espesor Trabe de Concreto armado Arq. Lizbeth Luis lizili20 @hotmail.com Tuxtla Gtz., Chiapas

Language	Spanish
Drawing Type	Section
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Aluminum, Concrete, Glass
Measurement Units
Footprint Area
Building Features
Tags	adobe, autocad, bausystem, construction system, constructive, covintec, DETAIL, DWG, earth lightened, erde beleuchtet, facade, flagstone, inclined, losacero, panel, plywood, section, sperrholz, stahlrahmen, steel framing, structuring, système de construction, terre s, window, windows
