Septic Tank DWG Block for AutoCAD

Septic Tank DWG Block for AutoCAD

Well Septic

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Brick masonry, C, Galv mesh, Cue waterproof well, your B. Heavy pvc, Arrives from the main network, Sedimentation pond, Filter pit, Tee type filter mesh, Septic tank plant, scale, Septic tank section, scale, Percolation well, Distrib., Cover cº waterproofing, Galv mesh, Sedimentation pond, Filter pit, Percolation well, Distrib., Heavy PVC elbow, Tee type filter mesh, your B. Heavy pvc, N.p.

Raw text data extracted from CAD file:

3,10 1,93 0,80 1,97 2,20 1,70 0,80 2,20 0,20 1,83 0,15 0,73 0,20 1,93 0,10 0,45 0,25 3,00 3,22 2,30 0,82 3,20 MAMPOSTERIA DE LADRILLO CAJA DE PASO Cº 175 km/cm2 MALLA GALV 1/2" x 1/2" POZA Cº 210 kg/cm2 impermeabilizado TUB. PVC PESADO Ø 4" TUB. PVC PESADO Ø 4" TUB. PVC PESADO Ø 4" llega de la red prinipal de desgue Poza de sedimentacion Poza filtro TEE enmallada tipo filtro 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 5 POZO SEPTICO - PLANTA ESCALA : 1/50 POZO SEPTICO - SECCION A-A ESCALA : 1/50 A A Pozo de Percolacion Pozo de Distrib. TAPA Cº 210 kg/cm2 impermeabilizado TAPA Cº 210 kg/cm2 impermeabilizado TAPA Cº 175 kg/cm2 impermeabilizado MALLA GALV 1/2" x 1/2" Poza de sedimentacion Poza filtro Pozo de Percolacion Pozo de Distrib. CODO PVC PESADO 90 x 4" CODO PVC PESADO 90 x 4" TEE enmallada tipo filtro 5 5 5 5 5 TUB. PVC PESADO Ø 4" N.P.N. N.P.N. N.P.N.

Language	Spanish
Drawing Type	Block
Category	Water Sewage & Electricity Infrastructure
Additional Screenshots
File Type	dwg
Materials	Masonry
Measurement Units
Footprint Area
Building Features
Tags	autocad, block, DWG, kläranlage, septic, tank, treatment plant
