Sewer Drainage DWG Section for AutoCAD

Sewer Drainage DWG Section for AutoCAD

Slope pipe – Sections- Control

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

detail, esc, drainage pipe fastening, obs.:measures given in cms., cm fe, ground floor level, fastening hook, downspout, p.v.c. mm, Conection, inverted, short curve, Caño Camara, inspection, elbow, inverted, pipe, fan spout, downspout, drain pipe detail, esc, Caño Camara, inspection, p.v.c., downspout, fastening hook, cm fe

Raw text data extracted from CAD file:

DETALLE esc. 1/5 SUJECION CAÑO DE DESAGUE OBS.:Medidas dadas en cms. FE d 1" - 2.5 cm NIVEL PLANTA BAJA GANCHO DE SUJECION CAÑO DE BAJADA P.V.C. Ø75 mm P.V.C.-100x100 mm CONECCION "Y" P.V.C.-100x50mm "Y" INVERTIDA CURVA CORTA 90º P.V.C.-100x100mm CAÑO CAMARA P/ INSPECCION CODO 45º P.V.C.-100x100mm "Y" INVERTIDA P.V.C.-100x50mm CAÑO DE BAJADA-P.V.C. Ø100mm Ø100mm CAÑO VENTILADOR Ø100mm CAÑO DE BAJADA DETALLE CAÑO DESAGUE esc. 1/5 Ø100mm CAÑO CAMARA P/ INSPECCION P.V.C. Ø100mm CAÑO DE BAJADA GANCHO DE SUJECION FE d 1" - 2.5 cm Ø100mm
