Sewer Inlet DWG Detail for AutoCAD

Detail well of sewer inlet

Drawing labels, details, and other text information extracted from the CAD file (Translated from Catalan):

Maintenance services, Town hall, Flat designation:, From barcelona, Date:, Scale:, File:, Nº plan:, Clabsa, Xxxx, File.dwg, The following provisions are admitted:, Tub pvc, Curb mailbox, Well of fall, Register well in situ, Top of record, Medium cane molding, Concrete, Notes: the connection collectors do not always have registration wells. The type of well is given by the chips the tube of connection of the sink to the collector must be rectilinear. The turns are expressly prohibited as well as the ramifications of several sinks in the same tube. Direct connections are also prohibited vertically on the return of the collector. Several sinks can be connected between the wells so that the sinks have a direct connection to the sink with another sink, Collector detail collector sink not visible, Sewer connection detail, Collector not visitable, Wells of, July

Raw text data extracted from CAD file:

Manteniment i Serveis Ajuntament DESIGNACIÓ PLÀNOL: de Barcelona DATA: ESCALA: 0 ARXIU: Nº PLÀNOL: CLABSA XXXXXX-XXXXXXXXXXX XXXXXX-xxxxxxxxxxxxxxxxxxxxx XXXXXX-xxxxxxxxxxxxxxxxxxxxx 1/XXXX X m XX XXXXXXXXX, XXXX ARCHIVO.DWG \A1;0.70 \A1;0.30 \A1;0.35 \A1;0.35 S'admeten les disposicions següents: NO SI NO SI SI Tub d400 PVC (Min.) Vorada bústia Pou de caiguda h ³ 1.5m Pou de registre in situ Tapa de registre \A1;Calçada 5 Mitja canya d'emmotllament Formigó HM-15 5 5 5 NOTES: - La connexió a col.lectors no visitables, sempre ha de produir-se a pous de registre. - El tipus de pou ve donat per les fitxes 08.** - El tub de connexió de l'embornal al col.lector haurà de ser rectilini. Es prohibeixen expressament els girs en planta, així com les ramificacions o entroncaments de múltiples embornals a un mateix tub. - Estan també expressament prohibides les connexions directes en vertical sobre la volta del col.lector. - Es poden connectar diversos embornals entre si, a nivell dels pous de caiguda, de manera que els embornals "secundaris" tinguin connexió directa (d³300, pendent³5% i d£12m) amb l'embornal "principal", mai amb un altre embornal "secundari". DETALL DE COL.LELCTOR D'EMBORNAL A COL.LECTOR NO VISIBLE (Tipus Translínea) DETALL DE CONNEXIÓ D'EMBORNAL A COL.LECTOR NO VISITABLE (Sempre a pous de registre) 1/25 0.5 m 04.03 JULIOL 2002 DC0403.DWG

Language	N/A
Drawing Type	Detail
Category	Water Sewage & Electricity Infrastructure
Additional Screenshots
File Type	dwg
Materials	Concrete, Other
Measurement Units
Footprint Area
Building Features
Tags	autocad, DETAIL, DWG, inlet, kläranlage, sewer, treatment plant
