CONSTRUCTION OF ROOFING GARAGE FOR CONSOLIDATION BASED STRUCTURAL FOUNDATION IN PTR ANCLADO

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

structural plant carport, finished floor level, foundation, thick wood deck, waterproofing layer of thickness, cut, finished floor level, foundation, cut, waterproofing layer of thickness, thick wood deck, home, est inno, template, foundation, structural details ptr

Raw text data extracted from CAD file:

C-1 C-1 L-1 L-1 L-1 L-1 L-1 L-1 0.47m 5.53m 4.93m 1.21m 1.16m 1.16m 1.16m 1.21m 6.00m A A B B Planta Estructural Cochera L-1 C-1 L-1 L-1 L-1 C-1 Nivel de piso terminado Cimentacion Cimentacion L-1 L-1 Cubierta de madera de 2cm de espesor (triplay) Capa de impermeabilizante 1cm de espesor L-1 1.21m 1.16m 1.16m 1.16m 1.21m Corte A-A 2.25m 2.58m 3.28m C-1 Nivel de piso terminado Cimentacion Corte B-B L-1 L-1 2.4m 3.1m Capa de impermeabilizante 1cm de espesor Cubierta de madera de 2cm de espesor (triplay) 5.53m 0.47m L-1 CASA 3.00m 4var 3/8" Est.No 3@20cm Plantilla de 10cm f´c=100kg/cm2 60cm 10cm Cimentacion L-1 C-1 6" 4" 4" 4" Detalles estructurales PTR

Language	Spanish
Drawing Type	Detail
Category	Construction Details & Systems
