Support for pipe 8

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

long plate, description, item, cant., unity, piece, fire protection system, support anchored in rainwater channel, pipe support, angles long., piece, platen, front view, isometric view, side view, meter, linear, piece, screws long, piece, Thread bar with nut, piece, posterior isometric view, ipe beam, pipelines, Thread bar with nut, ipe beam, Thread bar with nut, pipelines, pipelines, Thread bar with nut, ipe beam, Threaded bar long, ipe beam

Raw text data extracted from CAD file:

\A1;500 \A1;150 \A1;175 \A1;500 \A1;116 \A1;140 \A1;210 \A1;174 \A1;1 3/4" PLETINA 1 1/4" x 3/16" x 180 LONG. DESCRIPCION ITEM 112 111 CANT. UNIDAD 25 PIEZA PIEZA SISTEMA DE PROTECCION CONTRA INCENDIO SOPORTE ANCLADO EN CANAL DE AGUA DE LLUVIA SOPORTE PARA TUBERIAS d4" ANGULOS 50 x 50 x 5 x 50 LONG. PIEZA 25 114 25 PLETINA 1 1/4" x 3/16" VISTA FRONTAL VISTA ISOMETRICA VISTA LATERAL METRO LINEAL 113 PIEZA 25 3.750MTS. 111 TORNILLOS 1/2" x 1 1/2" LONG. 115 25 PIEZA BARRA ROSCA CON TUERCA 116 25 PIEZA VISTA ISOMETRICA POSTERIOR 112 113 114 115 112 115 113 114 111 VIGA IPE 80 x 46 TUBERIAS d4" BARRA ROSCA CON TUERCA 117 VIGA IPE 80 x 46 112 113 114 BARRA ROSCA CON TUERCA TUBERIAS d4" 111 116 115 500 150 175 \A1;116 TUBERIAS d4" BARRA ROSCA CON TUERCA VIGA IPE 80 x 46 111 114 115 113 116 500 116 140 210 174 4.500MTS. 1..250MTS. BARRA ROSCADA 1/2" x 150 LONG. BARRA ROSCADA 1/2" x 150 LONG. 3.750MTS. 116 1 3/4" VIGA IPE 80 x 46 13.50MTS.

Language	Spanish
Drawing Type	Block
Category	Mechanical, Electrical & Plumbing (MEP)
