System Surge Arrester DWG Block for AutoCAD
Circuit for the protection of electrical and electrotechnical equipment from surges of atmospheric origin and industry.
Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):
mmmm, important transient overvoltage limiters protect electronic electrical equipment against transient overvoltages of industrial atmospheric origin. the transient overvoltage limiter is chosen according to the level of risk of the location of the sensitivity of the material to be protected. if there is a receiver for example of microinformatics it is recommended to add a second limiter of a line distance greater than m. for this case the de de according to the assembly instructions provided by the manufacturer can be used. be careful to install upstream of a differential protector., of application iram iec, notes a high leakage current linked to performances beyond the benefits of the overvoltage limiter activates its internal protection consequently end of life signaling. the opening of the circuit-breaker may occur during a direct fall of the beam on the line. the end-of-life signaling of the overvoltage limiter is verified by its short-circuit. the end of life needs its replacement. with signaling the continuity of the connected to the closure of the upstream circuit breaker. a remote fault signal of the overvoltage limiter is achieved using the terminals of a fault indicator sd a light pilot. the default signaling contact indicates the disconnection of the switch by coil of min., transient overvoltage arrester standard: nf type: schneider code: uc imax: residual voltage wave: with test button step width: din modules, dst, light pilot light on door holes mm minimum distance between centers: mm, qpst, qsd, defect signaling contact sd code schneider step width: din modules coupling: the left of the qpst switch by mechanical interlock, bicolor, …, three-phase, two color, grounding conductor, main input bars, bar of potential compensation, protection zone, waveform, tt system grounding, curve type thermomagnetic switch, q, bar of potential compensation, transient surge arrester, engineering and, zarranz, work: against atmospheric discharges, revision date draw approved scale print, plan no, principal:, qpst, dst, transient overvoltage arrester, qsd sd, bright
