Terrace Detail DWG Detail for AutoCAD

Terrace Detail DWG Detail for AutoCAD

Flat roof not passable invested

Drawing labels, details, and other text information extracted from the CAD file (Translated from Galician):

Galvanized sheet, Auction, Isolation, Heavy protection, Protection auction, Galvanized sheet of, Plastered, Separation sheets, Foot l.c.v., Palace, Perimeter zuncho, Isolation, Plastered, L.h.s., Plaster, Foot l.c.v., Palace, Lamina de, Meabilizacion, Flat non-passable inverted cover, Scale, Quotas in cm., Forged semivokes, Ceramic swirl, Plaster, Isolation band, Concrete of earrings, Waterproofing sheet, Plated l.c.v., Palace

Raw text data extracted from CAD file:

11.5 6 4 1.5 \A1;4 \A1;6 \A1;11.5 \A1;1.5 CHAPA GALVANIZADA DE REMATE AISLAMIENTO PROTECCION PESADA REMATE Y PROTECCION CHAPA GALVANIZADA DE ENFOSCADO LAMINAS DE SEPARACION 1/2 PIE L.C.V. PALAU ZUNCHO PERIMETRAL AISLAMIENTO ENFOSCADO L.H.S. ENLUCIDO 1/2 PIE L.C.V. PALAU LAMINA DE IMPER- MEABILIZACION CUBIERTA PLANA NO TRANSITABLE INVERTIDA ESCALA 1:10 COTAS EN cm. 4 6 1 11.5 1.5 FORJADO DE SEMIVIGUETA Y BOVEDILLA CERAMICA ENLUCIDO BANDA DE AISLAMIENTO HORMIGON DE PENDIENTES LAMINA DE IMPERMEABILIZACION CHAPADO L.C.V. PALAU

Language	N/A
Drawing Type	Detail
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete
Measurement Units
Footprint Area
Building Features
Tags	autocad, barn, cover, dach, DETAIL, DWG, flat, hangar, invested, lagerschuppen, passable, roof, shed, structure, terrace, terrasse, toit
