Wash Basin DWG Block for AutoCAD

Installation of wash basin

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

p.v.c., ventilation, sink., Specifications., key., feeder., drill cover, drain., mod., mod. white tampico, to superimpose ideal standard, brass diameter cespol, chromed brass., of angular retention, economizadora with automatic closing mca. helvex, chromed diameter bronze with key, chromed with sheet metal, vent, tube p.v.c., note:, tube p.v.c., vent, drain p.v.c., p.v.c. tee, n.p.t., copper tube mm, a.f., drain, n.p.t., notes, if the project indicates it., Centimeters the diameters in millimeters., the toilet ventilation will only anger, all lengths are bounded in, detail of washbasin with cold water.

Raw text data extracted from CAD file:

d38 P.V.C. VENTILACION LAVABO. ESPECIFICACIONES. LLAVE. ALIMENTADOR. CUBRETALADRO. DESAGUE. MOD. TV-105 MOD. TAMPICO BLANCO 01-016 DE SOBREPONER IDEAL STANDAR CESPOL "P" DE 32mm. DE DIAMETRO DE LATON O LATON CROMADO. DE RETENCION ANGULAR ECONOMIZADORA CON CIERRE AUTOMATICO MCA. HELVEX DE BRONCE CROMADO DE 10mm. DIAMETRO CON LLAVE BRONCEADO, CROMADO CON REGISTRO, CONTRA Y CHAPA 5 d38 VENT. 38d TUBO P.V.C. 47 d13 52 NOTA: (B) TUBO P.V.C. VENT. 38d d13 P L A N T A DE 38x38x38. DESAGUE d38 P.V.C. TEE DE P.V.C. 50 55 C O R T E N.P.T. TUBO DE COBRE d13 mm A.F. d13 d13 d38 d38 DESAGUE N.P.T. B) A) NOTAS : E L E V A C I O N SI LO INDICA EL PROYECTO. 79 CENTIMETROS Y LOS DIAMETROS EN MILIMETROS. LA VENTILACION DE LAVABO IRA UNICAMENTE TODAS LAS LONGITUDES ESTAN ACOTADAS EN SIN/ESC. DETALLE DE LAVABO CON AGUA FRIA.

Language	Spanish
Drawing Type	Block
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials
Measurement Units
Footprint Area
Building Features
Tags	autocad, basin, block, DWG, einrichtungen, facilities, gas, gesundheit, installation, l'approvisionnement en eau, la sant, le gaz, machine room, maquinas, maschinenrauminstallations, provision, wash, wasser bestimmung, water
