Well absorbent for removing sewage

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Masonry wall, bonnet, Fd, Concrete cap, entry, P.v.c., Concrete rings, Anchorage, elbow, Pvc adapter, Concrete cap, ventilation, Plant ventilation, Perforated concrete rings, In permeable zone, cut, Plant esc .:, absorbent

Raw text data extracted from CAD file:

14 \U+22051,2 0,45 2 0,5 0,5 Muro de mamposteria e=20cm. Sombrerete FºDº Ø100mm. Tapa de hormigón Te Ingreso C°P.V.C.Ø110mm. +0,00 Te A ventilación.Ø110 P.V.C. Aros de hormigón Ø1100mm. Anclaje de H° Codo 90°P.V.C.Ø110mm. Adaptador P.V.C a F°D° Tapa de hormigón Ventilación Planta Ventilación -14,45 Aros de Hormigon Perforados en zona Permeable \W6.92252; CORTE A-A Esc.:1:50 \W6.18451; PLANTA Esc.: 1:50 \W8.32262; A \W8.32262; A 14 \LPOZO ABSORBENTE 5 5 5 5 5
