Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Cross mn, Unipolar disconnector blades apt loadbuster, Ozn surge arrester, Insulator bell pin necklace, retention, Nm., Bond mn, Cu cu, Ground, Hose, Wooden cross-piece, Ground, Hºgº opgw mount, Hose, Hg

Raw text data extracted from CAD file:

CRUCETA MN 525a SECCIONADOR UNIPOLAR A CUCHILLAS APTO LOADBUSTER 33kV - 400A DESCARGADOR DE SOBRETENSION OZn 30kV-10kA AISLADOR CAMPANA MN14 PERNO MN414 COLLAR MN251 \W0.7;CADENA DE RETENCION S/TN 212a1 MENSULA DE RETENCION MN 525A VINCULO MN 168 \W0.7;C.S 3x1x120mm2 Cu C/PANTALLA 50mm2 Cu \W0.7;ABRAZADERA MN104c PUESTA A TIERRA CAÑO HºGº d6"x 6mts. CRUCETA DE MADERA MN110 PUESTA A TIERRA HºGº OPGW A MONTAR CAÑO HºGº d6"x 6mts. CAÑO HºGº d6"x 6mts. (RETIRAR HºGº EXISTENTE)
