Detail Of Lamp / Pool / Mechanical Room Section DWG Section for AutoCAD

Detail Of Lamp / Pool / Mechanical Room Section DWG Section for AutoCAD

Pool luminaire detail with electrical wiring and mechanical room – section

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

connection box, grass, finished floor, thhn, tpg, conduit, niche, damp, water level, detail lamp assembly in pool, glass thickness according to, manufacturer specifications., trans, machine room, conduit, thhn, splice, lamp sealed to prevent water ingress.

Raw text data extracted from CAD file:

.45 .60 \A1;.45 \A1;.60 Caja de Conexión SJB-30 Césped Piso Terminado 1#12 THHN (T) 3#8 TPG Conduit 32mm Nicho Húmedo Nivel de Agua DETALLE MONTAJE DE LÁMPARA EN PISCINA (sin escala) .45 .60 Vidrio de Seguridad, grosor según especificaciones del fabricante. TRANS CUARTO DE MÁQUINAS Conduit 32mm 3#8 THHN Empalme Lámpara sellada para evitar entrada del agua.

Language	Spanish
Drawing Type	Section
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials	Glass
Measurement Units
Footprint Area
Building Features	Pool
Tags	autocad, beleuchtung, DETAIL, DWG, electrical, equipamentos de iluminação, iluminação, l'éclairage, lamp, lâmpada, lampe, lantern, lanterna, lanterne, laterne, les luminaires, leuchten, lighting, luminaire, Luminaires, mechanical, POOL, room, section, wiring
