Detail Septic Tank Pvc DWG Detail for AutoCAD

Detail Septic Tank Pvc DWG Detail for AutoCAD

Detail connecting septic tank PVC aintubated; with accessories oring

Drawing labels, details, and other text information extracted from the CAD file (Translated from Galician):

Countertop cement, Sand, Septic camera, Prefabricated lid, Cement mortar, Prefabricated lid, Cover, Npt, Ntn, Septic camera detail

Raw text data extracted from CAD file:

Contrapiso Cemento Arena 1-3 Cámara séptica h=1.40m Ø=0.90m Tapa Prefabricada Ø1.10m Mortero Cementicio 1-3 Mortero Cementicio 1-3 Mortero Cementicio 1-3 Mortero Cementicio 1-3 Tapa Prefabricada 70x70cm Tapa Ø110mm -2.82 NPT 0.00 -0.78 -1.89 -17.50 NTN -0.55 Detalle Camara Séptica
