Extension Industrial Body DWG Section for AutoCAD

Extension Industrial Body DWG Section for AutoCAD

Plant ,section, measures of extension industrial body

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

projection metal truss, existing construction, metal structure according to calculation, lift gate, project, scale :, plane :, location :, work :, extension ship, san luis cap., file :, plant, cut

Raw text data extracted from CAD file:

5,2 5,2 5,2 5,2 5,2 4,91 31,1 6,48 ±0.00 1,4 7 12 22 1,61 1,6 1,61 1,035 5 5 5 5 5 5 5 5 ±0.00 ±0.00 PROYECCION CABRIADA METALICA PROYECCION CABRIADA METALICA 5 CONTRUCCION EXISTENTE CONTRUCCION EXISTENTE 5 5 ESTRUCTURA METALICA SEGUN CALCULO P= 6º PORTON DE LEVADIZO RAMPA PENDIENTE 4 % 5 5 5 5 5 PROYECTO 1:100 HOJA N°: ESCALA: 1 PLANO: UBICACION: OBRA: AMPLIACION NAVE SAN LUIS CAP. PLANTA / CORTE ARCHIVO: AMPLIACION NAVE RAMPA PENDIENTE 4 % + 0.69 + 0.00 PROYECCION CABRIADA METALICA PROYECCION CABRIADA METALICA PROYECCION CABRIADA METALICA PLANTA CORTE
