Medium Voltage DWG Detail for AutoCAD

Medium Voltage DWG Detail for AutoCAD

PLANTS , ELEVATIONS OF ELÉCTRIC DETAILS OF MEDIUM VOLTAGEE; COMO LO SON POSTE CON CORTA CORRIENTES; RETENIDAS; ANCLAJE; ETC.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

structure, The isolators of the retained ones must remain m. from the floor., Double anchor retainer, Retained stake anchor, Single anchor retainer for medium voltage line, note:, In case the retained crosses with another line of medium tencion install two isolators one next to the post another stake., Anchor seat retainer, When there is no construction, install a guard for retention., To see the compaction of the strain see standard, The length of the tube is in function of the width of the tube but should not exceed, The eye of the bolt should be parallel to the wall as close as possible to it., The cable of the retainer must be close to the limit of the property. See, Voltage of the conductors, Is used to retain conductors of medium voltage lines terminated with span See standard is also used to retain deflections up to any conductor gauge., structure

Raw text data extracted from CAD file:

3,5 45° 45° 5,5 1,7 3 N N N N N Estructura RD3N Estructura TS3N Estructura RD3N/RD3 Estructura AD3N N N N 5 5 Los aisladores de las retenidas deben de quedar a 3 m. del piso. RETENIDA DE DOBLE ANCLA RETENIDA A ESTACA Y ANCLA RETENIDA SENCILLA DE ANCLA PARA LINEA DE MEDIA TENSION NOTA: En caso de que la retenida cruce con otra linea de media tencion instale dos aisladoeres R, uno proximo al poste y otro a la estaca. RETENIDA DE BANQUETA Y ANCLA Cuando no exista construccion instale protector para retenida. Para ver la compactacion de la cepa vea norma 03 00 08. La longitud del tubo esta en funcion de la anchura de la banqueta, pero no debe exceder de 2,5 m, El ojo del perno debe debe quedar paralelo a ala pared y lo mas proximo posible a ella. El cable de la retenida debe quedar junto al limite de la rpopiedad. vea 03 00 08.. 5 5 5 Tension de los conductores 5 Se utiliza para retener conductores de lineas de media tension rematados con tramo corto, vea norma 05 00 01. Tambien se utiliza para retener deflexiones hasta de 30º co cualquier calibre de conductor. N N Estructura TS2N

Language	Spanish
Drawing Type	Detail
Category	Water Sewage & Electricity Infrastructure
Additional Screenshots
File Type	dwg
Materials	Other
Measurement Units
Footprint Area
Building Features
Tags	alta tensão, autocad, beleuchtung, DETAIL, details, détails électriques, detalhes elétrica, DWG, electrical details, elektrische details, elevations, haute tension, high tension, hochspannung, iluminação, kläranlage, l'éclairage, la tour, lighting, medium, plants, post, poste, son, torre, tower, treatment plant, turm, voltage
