Septic Tank DWG Block for AutoCAD

Septic Tank DWG Block for AutoCAD

Septic design for rural areas

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

General drainage scheme, Inspection box, Box of fats, Fishbone type, Open seam pipe, Long: mts, Septic tank, unscaled, Septic tank, In ccto. Psi with drain tub. stoneware, Removable cap, water level, building, Box casing, Entrance to, Stoneware pipe, Perforated, Stoneware pipe, Infiltration field, Exit to

Raw text data extracted from CAD file:

ESQUEMA GENERAL DE DESAGUES Caja de Inspección Caja de Grasas Tipo espina de pescado Tubería a junta abierta Long: 30 mts Pozo Séptico 2.40 2.40 2.40 2.40 SIN ESCALA POZO SEPTICO (Reforzada en ccto. 2500 psi con desagues Tub. Gres O4") 2.20 Mt TAPA REMOVIBLE NIVEL DEL AGUA 2.20 Mt CONSTRUCCIÓN A 12 cm 12 cm cañeria de la caja Entrada a la O6" Tuberia Gres A' 12 cm 1.10 12 cm 12 cm O4" Perforada 40 cm 30 cm Tuberia Gres 10 cm 1.20 Mt 10 cm 12 cm campo de infiltración Salida al
