Bathroom stipend in armed concrete and lined – Lateral view

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

common red wall wall, mirror of, pine frame, Anodized aluminum frame. alcomex, proportion repellent, flattened proportion, marble sink, mixer, marble plate, mortar cement sand provide pegamarmol, marble faldon, washbasin ovalin, Mca. helvex, Similary, concrete plate, wire, concrete plate, chrome plated, proportion repellent, cement crest similar, glazed ceramic tile

Raw text data extracted from CAD file:

0.01 0.2 0.08 0.09 0.2 0.03 0.2 0.12 0.02 0.04 0.62 5 5 5 5 5 5 5 5 5 5 5 MURO DE TABIQUE ROJO COMUN ESPEJO DE 6mm BASTIDOR DE PINO 1"x1 1/2" MOLDURA DE ALUMINIO ANODIZADAD 32998 MCA. ALCOMEX REPELLADO DE CEMENTO-ARENA PROPORCION 1:6 APLANADO DE CEMENTO-ARENA PROPORCION 1:5 ZOCLO DE MARMOL MEZCLADORA PLACA DE MARMOL MORTERO CEMENTO ARENA PROPORCION 1:3 O PEGAMARMOL FALDON DE MARMOL LAVABO OVALIN MCA. HELVEX O SIMILAR MESETA DE CONCRETO ARAMDO MESETA DE CONCRETO CROMADO 38mm REPELLADO DE CEMENTO-ARENA PROPORCION 1:6 PEGAZULEJO, CEMENTO CREST O SIMILAR AZULEJO O CERAMICA VIDREADA

Language	Spanish
Drawing Type	Block
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials	Aluminum, Concrete
