Valve Box DWG Block for AutoCAD

Box of valves.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Bronze valves of the network of, gravel, Hoof nipples, V.c., Union, handle, concrete, Grill cm., Box detail for, elevation, your B. Pvc, indicated, Interior plastered, Pvc adapter, Distribution of drinking water, Concrete cover, Angle frame, Comes from network, For metering valve, of distribution, gravel, Hoof nipples, V.c., Union, handle, concrete, Grill cm., Box detail, elevation, your B. Pvc, indicated, Interior plastered, Pvc adapter, measurer, Hydropneumatic for, Centrifugal pump horizontal, Pvc va, distribution network, Pumping equipment installation detail, Gal., Pressure, tank of, Manifold, Vc, tank of, Pressure, Gal., Vc, Pressure switch, iron, Engines, galvanized, Suctions, Glycerine manometer, Cover letter, V.check

Raw text data extracted from CAD file:

\A1;0.050 \A1;0.150 \A1;0.900 \A1;0.150 \A1;0.10 \A1;0.60 5 0.8999999999999986 5 0.60 VALVULAS DE BRONCE DE LA RED DE 5 5 Grava Niples de Ho Go V.C. Unión ASA d1/2" Concreto 210 Kg/cm2 Parrilla d3/8" @ 10 cm. DETALLE DE CAJA 0.60 X 0.60m. PARA ELEVACIÓN Tub. PVC d Indicado Interior Repellado Adaptador PVC Adaptador PVC DISTRIBUCIÓN DE AGUA POTABLE Tapadera de Concreto Marco de angulo 2X2X1/8" \A1;0.050 \A1;0.150 \A1;0.90 \A1;0.150 \A1;0.10 \A1;0.60 \A1;0.60 5 5 5 Viene de Red 0.60 PARA VALVULA Y MEDIDOR 5 5 de Distribución Grava Niples de Ho Go V.C. Unión ASA d1/2" Concreto 140 Kg/cm2 Parrilla d3/8" @ 10 cm. DETALLE DE CAJA 0.60X 0.60m. ELEVACIÓN Tub. PVC d Indicado Interior Repellado Adaptador PVC Adaptador PVC Medidor 5 HIDRONEUMATICO PARA CISTERNA DE 30M3 Capacidad/Unidad: Q=40GPM CDT=140pies 2 Bomba Centrifugas Horizontales PVC d2" va a Red de distribución DETALLE DE INSTALACIÓN DEL EQUIPO DE BOMBEO 220 gal. Presión Tanque de Manifold de V.C d11/4" Tanque de Presión 220 gal. V.C d11/4" V.C d2" Switch de Presión PP=60PSI PA=40PSI Hierro Motores 1F/208Volt. 2HP, 3500RPM Galvanizado d2" Succiónes Manómetro de Glicerina Caratula Ø2.5", 0-100PSI V.Check d2"
