Embedded drop manhole

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

well of visit with fallen terraced, concrete template armed with, cms. uniforms, anchors, cms., cms, cms., fallen terraced, armed with, with shoring, apparent concrete wall, fallen terraced, variable, concrete, brocal cover fo.fo., variable, cms, cms., minimum

Raw text data extracted from CAD file:

POZO DE VISITA CON CAIDA ADOSADA PLANTILLA DE CONCRETO ARMADO CON MALLA-LAC 6X6-10/10 40 CMS. UNIFORMES ANCLAS DE 3/8" / @ R 45 CMS. R 30 CMS. R 60 CMS 15.00 CMS. R 75 CMS. CAIDA ADOSADA METALICA) ARMADO CON MALLA-LAC 6X6-8/8 O F'C=150 KG/CM2 (COLADO CON CIMBRA MURO DE CONCRETO APARENTE CAIDA ADOSADA VARIABLE CONCRETO F'C= 150 KGS/CMS2 TAPA Y BROCAL DE FO.FO. VARIABLE 15.00 CMS 8" 120.00 15.00 60 CMS. MINIMO 60.00

Language	Spanish
Drawing Type	Block
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials	Concrete
