mooring roundown F.O.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Load of rupture of the staple: c.r.n. Of the cable, Connection clip, Slide tensioner, Thimble, Anchor retention, Splicing protection, Breaking load of the hardware: dan, denomination, Cant, Straight shackle, Twisted link

Raw text data extracted from CAD file:

CARGA DE ROTURA DE LA GRAPA: 95% C.R.N. DEL CABLE GRAPA DE CONEXIÓN TENSOR DE CORREDERA GUARDACABOS RETENCIÓN DE ANCLAJE EMPALME DE PROTECCIÓN CARGA DE ROTURA DE LOS HERRAJES: 12.500 daN DENOMINACION 2 7 CANT. 2 N 1 4 3 6 5 GRILLETE RECTO ESLABON REVIRADO 2 2 2 2 2 2 1380 105 320-500 48 M-16 68 24 6 7 1 2 3 4 5
