Septic Camera – Siphon Box DWG Section for AutoCAD

Septic camera – Siphon box – Plant – Section

Drawing labels, details, and other text information extracted from the CAD file (Translated from Portuguese):

cvrd, leaf:, rev .:, cvrd:, minerconsult:, Variable dimensions, scale, in centimeter except where indicated, grades, special siphon box, var., regularization mortar, he, the t, cut aa, lean concrete ballast, elf, handle on f. round, removable covers, variable c, plant, hermetic seal, var., Variable h, the, Variable l, minimum

Raw text data extracted from CAD file:

CVRD FOLHA: REV.: N° CVRD: N° MINERCONSULT: 3-PARA ELEVAÇÕES E DIMENSÕES VARIAVEIS VER INDICAÇÃO EM PLANTA 1-DES. S/ ESCALA 2-COTAS EM CENTIMETRO EXCETO ONDE INDICADO NOTAS CAIXA SIFONADA ESPECIAL - (CI.E) Ø VAR. ARGAMASSA DE REGULARIZAÇÃO 1:3 EL.E EL.T CORTE AA 10 8 20 15 LASTRO DE CONCRETO MAGRO EL.F ALÇA EM F. REDONDO Ø3/8'' (TIP.) TAMPAS REMOVIVEIS 8 8 15 6 9 3 6 ''C'' VARIAVEL PLANTA 4 26 VEDAÇÃO HERMÉTICA (TIP.) Ø VAR. ''h'' VARIAVEL EL.S ''L'' VARIAVEL A A MÍNIMO 20

Language	Portuguese
Drawing Type	Section
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials	Concrete
Measurement Units
Footprint Area
Building Features
Tags	autocad, box, camera, DWG, einrichtungen, facilities, gas, gesundheit, l'approvisionnement en eau, la sant, le gaz, machine room, maquinas, maschinenrauminstallations, plant, provision, section, septic, siphon, wasser bestimmung, water
